Small Wind Turbine Domestic Wind Turbine 2kw 24V-220V Wind Power with Low Rpm Permanent Magnet Generator

Product Description

Product Description High safety-realized all-weather continuous unattended operation.
1. With all-time pitch controlled regulation, the rotor speed is controlled to ensure the continuous operation under adverse wind condition.
2. The whole system is more secure as it's doubly protected by the auto safety protection (ASP) system.
Higher electricity production-with pitch controlled regulation, the output is 30% more electricity generated.
1. Above rated wind speed, the blade pitch angle is passively regulated with continuous full power output.
2.The working wind speed interval is larger with 3-25m/s.
Lower maintenance cost-no need maintenance in first 3 years, easily installation and maintenance, lower after-sales cost.
1. The key components are designed with ideas of free maintenance, no need after-sales maintenance in 3 years.
2. Tilt-up tower can ensure easily installation and maintenance of wind turbine.
Product Parameters

Model	JXBJX-2KW
Rated Power	2KW
Wind Wheel Diameter	3.2m
Blade Material	Reinforced FRP
Rated Rotation Speed	400 r/min
Start Wind Speed	2.5(m/s)
Rated Wind Speed	12(m/s)
Working Wind Speed	3-20m/s
Security Wind Speed	50m/s
Generator Type	Three-phase AC permanent magnet synchronous generator
Generator insulation grad	F
Speed regulation method	Mechanical centrifugal Pitch-controlled
Accept the direction of the wind	Upwind
Way of catch the wind direction	by tail vane
Protection in severe wind conditions	Pitch-controlled and ASP
Braking stop method	Intelligent control:Pitch-controlled then mechanical brake
Weight	120kg
Working temperature range	-25ºC~50ºC
Design life	20 years
Control Inverter	Off-grid: PWM Wind and Solar Hybrid Controller, Pure Sine Wave Inverter; On-grid: controller, on-grid inverter

Annual electricity production

Annual average wind speed	4m/s	5m/s	6m/s	7m/s
Annual electricity production (kWh)	2390	4200	6100	7876

Technical innovation point
1.The world's leading centrifugal pitch controlled technology
(1) Big positive blade angle for initial(+9°), acceleration performance is excellent, start up at 2.5m/s low wind speed.
(2) Below the rated wind speed,high-efficiency output.
(3)Above the rated wind speed, regulate pitch angle, keep the wind rotor rotate speed nearby the rated rotate speed, stable output power.
(4)Continuously running when wind speed within 3-25m/s (cover land common wind speed) , no need to brake for protection.
2.Tilt-up tower makes installation and maintenance simple and convenient.
(1)Without crane when install wind turbine in remote regions or islands.
(2)Only need a chain block when maintenance wind turbine, simple and low cost.
3.Remote monitoring
(1) Real-time grasp the running state of the wind power system and electricity production data.
(2)The wind turbine can be started, stopped or operated by remote command.
Our Advantages 1.Unique generator performance design, can be highly efficient output, power generation can be increased by 30% on the basis of the original;2.Unique wind power generation equipment technology greatly reduces the failure rate of the equipment.3.With R&D and design capability, the products are creative and novel, and the price is very competitive;4.A professional factory with advanced production lines and skilled workers;
5.Perfect technical support and good after-sales service;
Packaging & Shipping 1. Wind turbines use an inner foam layer to protect the outer plywood box.
2. Foam-packed towers only .
3. Controller inverters use inner carton outer plywood box.
4. Please refer to our sales instruction for package size and weight.
5. Sea freight consolidation or air freight.
If you have any requirements for packing and transportation, please let our sales staff know and we will do it according to your requirements.
Company Profile Tianjin Galaxy Tech Co., Ltd. is one of the leading manufacturers and exporters of small and medium wind turbines in China. We have more than 10 years of experience in manufacturing and selling small and medium wind turbines. We have a group of experienced wind turbine industry professionals who can provide professional wind power solutions according to customers' needs.At present, the main products are 200W-250KW horizontal axis wind turbine, vertical axis wind turbine, high efficiency variable pitch control wind turbine, off-grid wind turbine, on-grid wind turbine, civil wind turbine (domestic wind turbine or wind turbine for home use or home wind turbine system), wind-solar hybrid power system and various accessories. Applicable to power plants, farms, families, coastal areas, remote areas, islands, weather stations, outposts, tourist stations, etc.As a wind turbine factory, relying on the advantages of wind turbine manufacturers, we can provide high quality products and services as well as competitive factory price! Our GALAXY brand wind turbine systems have been exported to more than 70 countries and regions such as Europe, America, Africa, Middle East, Southeast Asia, Australia and so on. And we have won a worldwide reputation for reliable performance, stable quality and first-class after-sales service."Winning by quality, keeping faith by service" is our consistent business philosophy, 24 hours online service, OEM service, fast delivery time. We adhere to the business strategy of "product innovation, management innovation, service innovation". Based on the enterprise principle of "people-oriented, treating people with sincerity", we sincerely welcome new and old customers at home and abroad. We sincerely welcome new and old customers at home and abroad to visit our company and negotiate business. We are honored to have more and more customers' favor, trust and cooperation.
Certifications
After Sales Service High-quality after-sales service, escort for you!
After-sales service commitment1. Before shipment, we will carry out product quality inspection to ensure high quality products.2. During the warranty period, if there is any problem with the performance of the product, we will respond and provide technical support in time. 3. outside the warranty period, we will still provide customers with free technical support to ensure the normal use of the product. 44. We promise to provide detailed answers and counseling for any questions that customers may have during the purchase process.After-sales service precautions1. Please pay attention to the use of the product environment, so as not to affect the service life of the product.2. Please follow the product manual for operation to avoid failure caused by wrong use.3. Regularly check the condition of the product, if there is any abnormality, please contact us in time.We will wholeheartedly provide you with high quality after-sales service to ensure that you enjoy a worry-free shopping experience in the process of use. If you have any questions or needs in the process of use, please feel free to contact us. Wish you a happy use!
Detailed Photos
