Chint Ddsu666 Low Voltage Modular DIN Rail Products Single Phase DIN-Rail Meter
| US$19.29 | 1 Piece (MOQ) |
Basic Info.
Model NO.
DDSU666
Usage
Multi-Functional Energy Meter, Watt-Hour Meter, Meter for Industry and Home Use, Standard Electric Energy Meter
Electric Equipment
Single-phase
Theory
Electronic Meter
Power Meter Connection
Terminal
Measured Signal
Continuous Wave
Type
Energy Meter
Certification
ISO, CE
Customized
Customized
Dimensions
98mm*65mm*36mm
Weight
0.2kg
Ingress Protection
IP54
Digital Size
5.3mm*2.8mm
Communications
RS485
Connection Type
1p2w
Nominal Voltage
120V,220V,230V,240V
Frequency
50Hz or 60Hz
LED Display
Number of Flashes Per Kwh
Transport Package
Carton Packing
Specification
15*8*9CM
Trademark
CHINT
Origin
Zhejiang
Production Capacity
500000
Packaging & Delivery
Package Size
15.00cm * 8.00cm * 9.00cm
Package Gross Weight
1.500kg
Product Description
CHINT DDSU666 Low Voltage Modular DIN Rail Products Single Phase DIN-Rail Meter Detailed Photos Product Parameters| Measurement | Communications |
| Compliance with IEC60252-11 IEC62053-21 | RS485 |
| Connection type:1P2W | Protocol:Modbus and DL/T |
| Accuracy:Class 1.0 for active | |
| Environmental | |
| Voltage | Operating range limit:-40ºC to +75ºC |
| Nominal voltage(Un):120V,220V,230V,240V | Storage range limit:-40ºC to +85ºC |
| Operating range:0.7Un~1.2Un | Relative humidity:≤95%RH |
| Power consumption:≤1W,5VA | Ingress protection:IP54 |
| Current | Dimensions and Weight |
| CT:1.5(6)A | Dimensions:98mm ×65mm×36mm |
| DC:5(80)A | Weight:0.2 kg(Approx.) |
| Frequency | |
| 50Hz or 60Hz | |
| LCD Display | |
| 7 characters of 7 segment display | |
| Digital size:5.3mm×2.8mm | |
| LED Display | |
| Number of flashes per kWh | |
| Measured Values | |
| Total kWh | |
| Instantaneous kW | |
| Instantaneous Irms,Vrms,frequency,power factor | |
