Automatic Pallet Stackers/Magazine Inline Motorized Pallet Dispenser for Euro Pallets

Product Description

Inline Automatic Euro Pallets Pallet Dispenser Motorized Pallet MagazineProduct Overview:
The PM15E Automatic Pallet Dispenser is designed to optimize assembly line operations by providing efficient pallet distribution and temporary storage. It can function independently or in tandem with automatic palletizing machines, significantly improving packaging efficiency and reducing the need for manual labor. This versatile dispenser is widely applied across industries such as chemicals, electronics, food and beverages, papermaking, and building materials.
The machine features an electric lifting mechanism, four sets of pneumatic hooks, a conveyor section, and a PLC control system. It allows forklifts to load 12-15 pallets at once, eliminating the need for manual pallet addition and enhancing overall pallet handling efficiency.
Advantages:
1.Increased Efficiency
Automatically supplies 12-15 pallets at once, minimizing manual labor and boosting production line throughput for enhanced operational efficiency.
2.Flexible Customization
Offers customizable pallet magazines that accommodate various pallet sizes and site configurations, ensuring adaptability to different operational setups.
3.Fast Distribution
Adjustable conveyor speeds (15-28m/min) with a rapid distribution time of 25 seconds per pallet, ensuring seamless flow and quick material handling.
4.Energy-Efficient & Reliable
Consumes only 0.75kW of power, with multiple conveyor options, ensuring cost-effective, long-term, and stable operation in diverse environments.Product Gallery:Technical Parameters:

Pallet Material	Wooden or Plastic Pallets
Pallet Type	"Chuan" Type or "Tian" Type
Pallet Specifications	L800-1200 * W800-1200 * H120-150mm or Custom
Pallet Capacity	12 - 15 pcs
Lifting Method	Electric Lift
Lifting Height	200mm
Lifting Weight	600kgs (Customizable)
Conveying Speed	15-28m/min (Adjustable)
Distribution Speed	25 seconds/pc
Conveying Method	(Optional) Chain or Roller
Line Height	500 ± 50mm
Air Pressure	0.4 - 0.6Mpa
Power Supply and Power	Single Phase AC220V, 50Hz, 0.75kw / Three Phase Five Wire AC 380V 50Hz 0.75kw
Options:
Customizable pallet magazine to fit specific pallet dimensions and site layouts.
Select from roller, belt, or chain conveyors based on your operational needs.

ABOUT US:Founded in 2015, Heno Packaging Industries Co., Ltd. is a leading manufacturer of innovative, automated packaging solutions. Specializing in high-quality packaging machinery, including case erectors, case packers and sealers, pallet wrappers, pallet strapping machines and palletizers, we provide custom solutions tailored to meet the unique needs of various industries, including chemicals, food and beverage, electronics, and more.Based in Dongguan, Guangdong, our team of 15 dedicated employees is committed to delivering exceptional products that improve operational efficiency and reduce labor costs. With a strong focus on R&D and quality improvement, we pride ourselves on providing reliable, cutting-edge packaging solutions that drive business growth.Our products are sold to markets around the world, including Australia, New Zealand, Turkey, Russia, Spain, and Europe. With a production capacity of approximately 200 machines per year, we continue to build strong relationships with customers, ensuring world-class service and support at every stage of the project.At Heno, we are driven by our mission to innovate and provide sustainable, cost-effective packaging solutions that exceed customer expectations.
