Power Star 1000W-6000W Pure Sine Wave Solar Power Charger Inverter

Product Description

Power Star 1000W-6000W Pure Sine Wave Solar Power Charger Inverter
NEW FEATURES:
1. LCD Digital Display Panel, can show voltage, battery and load details and adjust voltage or frequency.
2. Add inside MPPT solar charger controller 12v/24v 40A. (Optional)
3. Add remote control LCD panel with 5meters length cable. (Optional)
Advantages:
l. Pure sine wave combined inverter charge
l. 4 step progressive charging 7 battery type selector
l. Easy to install & easy to use
l. Highpower,Multistage Battery charger
l. Automatically and swiftly line to battery switchover
l. High efficiency using lineinteractive circuit topology
l. Microprocessor control guarantees high reliability
l. Bypass without battery connected
When the POWER STAR LW is in the inverter mode, the ' through the box' earth line is automatically
disconnected from the input earth and joined to the output neutral, complying with the natural earth
inverter requirements if you what to maintain a trough earth simply connect the input earth to the
output earth.

Model No.	LW1000	LW2000	LW3000	LW4000	LW5000	LW6000
Nominal Power	1000W	2000W	3000W	4000W	5000W	6000W
AC Input
Phase & waveform	Single phase & Pure Sine Wave
Voltage	120VAC/230VAC
Acceptable Voltage	194-243VAC\164-243VAC(wide mode )
Line Low Transfer	85V±4%/184(154 wide mode±4%)
Line Low Return	95V±4%/194(164 wide mode±4%)
Line high Transfer	135V±4%/253±4%
Line high Return	127V±4%/243±4%
Frequency	50Hz or 60Hz (auto sensing)
Line Low Transfer	47Hz for 50Hz,57Hz for 60Hz
Line high Transfer	55Hz for 50Hz,65Hz for 60Hz
Output
Phase & waveform	Single phase & Pure Sine Wave ( bypass mode sync to input )
Voltage	120/220/230/240VAC ( bypass mode sync to input )
Voltage Regulation	±10%rms ( bypass mode sync to input )
Frequency	50Hz±0.3Hz ( bypass mode sync to input )
Peak Power	3 times of rating power
Short Circuit Protection	Yes,shutdown after 10ms
Power Factor	0.9-1.0
DC Input
Battery Voltage	12V/24V	12V/24V/48V		24V/48V
Minimum Start Voltage	10V for 12V,20V for 24V,40V for 48V
Low Battery Alarm	10.5V for 12V,21V for 24V,42V for 48V
Low Battery Transfer	10V for 12V,20V for 24V,40V for 48V
High Voltage Alarm	16V for 12V,32V for 24V,64V for 48V
Max Charging Current	35A/70A
Over Charge Voltage	15.7V for 12V,31.4V for 24V,62.8V for 48V
Transfer Efficiency
Line Mode	> 95%
Battery Mode	> 88%
power saver	Available when the load is less than 25 Watts
Indicators
7-LED Display	From the right to the left,LED1 line mode (green lighting) , LED2 inverter mode
	(green lighting) , LED3 charging mode ( yellow lighting ), LED4 Fully charged
	(green lighting) , LED5 over heat shutdown(red lighting ), LED6 Overloaded
	shutdown ( red lighting ), LED7 Saving Mode ( green lighting )
3-LED Display	Charging Mode(green lighting) , inverter mode(green lighting) , Alarm ( red lighting )
Switch selector	Saving Mode is on/off when push the switch forwards/backwards, keeping it horisontal is
	turning the inverter off.
Audible Alarm	Sounding when the heatsink's tem is over 105 °C and shutdown after 30 seconds.
Protections	low battery , over charging , over temp , over load
Communications	RS-232/USB(custom-made )
Enviromental
Operating Environment	0-40 °C ,0-90%RH(non-condensing)
Audible Noise	< 60dB
