Super-Above Truck Crane, 100ton Hydraulic Mobile Crane with Spare Parts in Stock
Basic Info.
Model NO.
TC-100
Certification
GS, RoHS, CE, ISO9001
Condition
New
Maximum Lifting Height
>40m
Maximum Lifting Weight
100ton
Shaft Number
3
Crane Jib
Five-Arm
Type
Folding
Overall Dimension
13930X2800X3575mm
Wheel Base
2304+2075mm
Track
2074/1834/1834mm
Max. Travel Speed
80km/H
Min. Travel Speed
3km/H
Min. Turning Diameter
24m
Min. Ground Clearance
327mm
Max. Grade Ability
40%
Application
Construction Lifting
Engine Rated Power
276/2200kw/(R/Min)
Engine Rated Torque
1500/1400n.M/(R/Min)
Approach Angle
19degree
Departure Angle
11degree
Braking Distance
Less Than10m
Max. Total Rated Lifting Capacity
100t
Transport Package
Nacked
Specification
CE
Trademark
Super-above
Origin
Jiangsu, China
HS Code
8705109100
Production Capacity
10000PCS/Year
Packaging & Delivery
Package Size
1150.00cm * 235.00cm * 256.00cm
Package Gross Weight
24500.000kg
Product Description
Super-above 100Ton Truck Crane Hydraulic Mobile Crane for saleSuper-above Truck crane is widely used for the lifting operations in general engineering projects, such as construction site, urban renewal, communication and transportation, ports, bridge, oilfields and mine, and complex working environments. * 6-section boom of 64 m with U-type profile is adopted; the max. lifting load is 100 t; the max. lifting height is 92.6 m; the max. working radius is 62 m; The performance takes the lead comprehensively. * Low speed large torque power transmission system, contributes to perfect combination of optimal power and optimal economical efficiency, leading to more than 12% reduction in fuel consumption and 10% improvement in grade ability. * SATC100 is also the first four-wheel driven truck crane domestically, which can meet the need under various road conditions.Chassis rear hydraulic controlled follow-up steering technology, realizate highway and small turning two steering modes, ensure stable and reliable of vehicle at high speed, travelling at lower speed is flexible.
Specifications of 70tons Hydraulic Truck Crane
| Description | Unit | Parameter value |
| Overall length | mm | 13900 |
| Overall width | mm | 2800 |
| Overall Height | mm | 3575 |
| Wheel Base | mm | 2304+2075 |
| Total vehicle mass in travel configuration | kg | 43000 |
| Engine Model | WD615.338 | |
| Engine rated power | kw/(r/min) | 276/2200 |
| Engine rated torque | N.m/(r/min) | 1500/1400 |
| Engine rated rotational speed | r/min | 2100 |
| Max. travel speed | km/h | 80 |
| Min. steady travel speed | km/h | 3 |
| Min. turning diameter | m | 24 |
| Min. turning diameter at boom tip | m | 29 |
| Min. ground clearance | mm | 327 |
| Max. grade ability | % | 40 |
| Approach angle | ° | 19 |
| Departure angle | ° | 11 |
| Braking distance (at 30 km/h, full load ) | m | ≤10 |
| Oil consumption per 100km | L | 45 |
| Max. total rated lifting capacity | t | 70 |
| Min. rated working radius | m | 3 |
| Turning radius at turntable tail | mm | 3550 |
| Max. load moment Base boom | KN.m | 2303 |
| Max. load moment Fully-extended boom | KN.m | 1129 |
| Max. load moment Fully-extended boom + Jib | KN.m | 580.2 |
| Hoist height Base boom | m | 11.8 |
| Hoist height Fully-extended boom | m | 44.2 |
| Hoist height Fully-extended boom + Jib | m | 59.4 |
| Boom length Base boom | m | 11.6 |
| Boom length Fully-extended boom | m | 44.5 |
| Boom length Fully-extended boom + Jib | m | 59.5 |
