Injection Blow Machine for Plastic Pipe

Product Description

Ningbo Union Power Machinery Co., Ltd.
Welcome to Ningbo Union Power Machinery Co., Ltd.
Our factory, located near Shanghai in Ningbo, specializes in manufacturing injection molding machines, injection molds, and auxiliary equipment. We offer a wide range of injection molding machines, from 50 tons to 3000 tons, with a tensile resistance of up to 40000 g. Our machine family includes:
Standard Injection Molding Machine
PVC Injection Molding Machine
PET Injection Molding Machine
Two-Color Ejector
Fully Hydraulic Injection Molding
All-Electric Injection Molding Machine
China Servo Injection Molding Machine
Key Specifications:
Modulus of Capacitance: Includes position, size, maximum allowable modulus, and minimum closure thickness of the injection molding machine guide pillar (Green column).
Nozzle Parameters: Spherical diameter, aperture, outer diameter, maximum extension length, and positioning aperture of the nozzle.
Code Mold Parameters: Features code mold hole and slot size.
Ejection Mechanism: Specifies ejection point position, ejector rod diameter, ejection force, and ejection stroke if needed.
Mold Opening Stroke: Indicates mold opening stroke and maximum opening distance.
For high-quality injection molding machines and equipment, trust Ningbo Union Power Machinery Co., Ltd. to meet your manufacturing needs.

Technical Parameters	Model UP-300T
Injection Unit	A	B	C
Screw diameter (mm)	60	65	70
Shot Volume (cm3)	806	946	1096
Injection weight (g)	725	851	987
injection pressure (Mpa)	170	145	107
Screw speed (rmp)	220
Clamping Unit
Clamping force (KN)	3000
Open stroke (mm)	600
Max Mold height (mm)	620
Min Mold height (mm)	200
Space between tie bars(mm)	620*620
Ejector force (KN)	70
Ejector stroke (mm)	150
Others
Pump pressure (Mpa)	16
Motor/driving power (KW)	30(29)
Heating power (KW)	18.5
Machine dimension (M)	6.3*1.75*2.37
Machine weight (T)	9.3
Oiltank cubage (L)	400
