Indoor Outdoor P3.91 P2.8 P1.9 Transparent Digital Advertising Glass Video Wall RGB SMD TV P3.91-7.8 P2.8-5.6 Curtain Window LED Panels Mesh Film Display Screen

Product Description

Specification

Model	TGC1.9	TGC2.8	TGC3.9	TGC3.9	TGC5.2
Pixel Pitch(mm)	H1.9-V3.9	H2.8-V5.6	H3.9-V7.8	H3.9-V7.8	H5.2-V10.4
Pixel Matrix Per Sq.m	129,024	61,952	32,768	32,768	18,432
Pixel Configuration	SMD1515	SMD1921	SMD1921	SMD1921	SMD1921
Brightness (nits)	3,000	5,500	3,500	5,500	5,500
Scan	1/14	1/11	1/8	1/8	1/6
Cabinet Resolution	504x128	352x88	256x64	256x64	192x48
Transparency	30%	50%	70%	70%	80%
Power Con. (Max / Avg)	800/360w/sq.m	800/360w/sq.m	400/180w/sq.m	800/360w/sq.m	800/360w/sq.m
Module Dimension	500x125mm /1.64x0.41ft
Cabinet Dimension	1000x500mm / 3.28x1.64ft
Cabinet Material	CNC Aluminum
Cabinet Weight	5 kg
Service Access	Front & Back
Refresh Rate (HZ)	1,920
Viewing Angle (H/V)	160/160
IP Rate	IP24
Operation Temperature	-40° ~ 45°
Input Voltage (AC)	100V or 240V

Model	TGC7.8	TGC7.8	TGC10.4	TGC10.4
Pixel Pitch(mm)	H7.8-V7.8	H7.8-V7.8	H10.4-V10.4	H10.4-V10.4
Pixel Matrix Per Sq.m	16,384	16,384	9,216	9,216
Pixel Configuration	SMD1921	SMD1921	SMD1921	SMD1921
Brightness (nits)	3,500	5,500	3,500	5,500
Scan	1/4	1/4	1/3	1/3
Cabinet Resolution	128x64	128x64	96x48	96x48
Transparency	70%	70%	80%	80%
Power Con. (Max / Avg)	400/180w/sq.m	800/360w/sq.m	400/180w/sq.m	800/360w/sq.m
Module Dimension	500x125mm /1.64x0.41ft
Cabinet Dimension	1000x500mm / 3.28x1.64ft
Cabinet Material	CNC Aluminum
Cabinet Weight	5 kg
Service Access	Front & Back
Refresh Rate (HZ)	1,920
Viewing Angle (H/V)	160/160
IP Rate	IP24
Operation Temperature	-40° ~ 45°
Input Voltage (AC)	100V or 240V

Company Profile LEDFUL is a top LED display manufacturer with 13 years rich experience providing 3 years warranty.
We concentrate on LED Poster, Transparent LED screen, Outdoor & Indoor commercial LED billboard,
Rental LED screen, Sports LED display.
Certifications Due to our best balance of quality & price with strong reputation, our LED displays are exported to 83
countries in Europe, America, Asia, Africa, and Oceania with successful 5600 projects. Besides LEDFUL
obtained CE, FCC, RoHS, CCC, UL, ETL, EMC, ISO9001 certificates. A state-of-the-art manufacturing
and testing facility ensures LEDFUL products of the high and stable quality.
Each product goes there 16 monetary procedures 23 operating procedures in 1500 tests and experiments.
Packaging & Shipping All employees are honest, responsible and diligent. Dedicated to professional,
high efficient and caring features, our experienced sales engineers listen to you,
think more for you.
In addition, take good care of each detail of your order, packages and shipping.
We also welcome deep customized, OEM, ODM orders and distributors application.
LEDFUL is a trusted one-stop LED display solution provider with more designs and more solutions.
Our partners are media advertising, audio, video & light, retail, property, religion, sports, event, studio.
Front service, double sided, column, flex, curved, sphere, 90 degrees, any irregular shaped LED display
are available.
Our corporate philosophy is to maximize the value for our customers and to provide the best service for
our customers. FAQ 1.Q:What's the weight of TGC cabinet?
A:The weight of one TGC 1000x500mm cabinet is 5kg"
2.Q:Can it be used outdoors?
A:We have recently launched the outdoor TGC cabinet customized design, can be used outdoors with IP65 grade"
3.Q:Are the screen sizes standardized? Can it be customized?
A:Our standard screen size is 1000*500mm cabinet, module size is 500*125mm, can be customized according to the module size. If the size of special requirements can also be designed, add a portion of expenses"
4.Q: Are you trading company or manufacturer?
A:LEDFUL is a professional LED display manufacturer, having been enrolled in led display industry with professional
R&D team and skilled QC team for 13 years.
5.Q: What is the control system? How is it?
A: We use Nova Taurus Series asynchronous control system. Support cluster play and management.
Support APP/Phone/WIFI Ipad/Laptop/PC/Cloud control. It's very easy and convenient to control.
6.Q: What is your best service?
A: One to one sales engineer to customer responsibility system. We will do:
1) Know your project and provide the best solution for it.
2) Track your order and let you know each step and detail of it.
3) Teach you how to install and use the screen.
4) Care the subsequent use of your screen and ensure vour after -sales service be well.
7.Q: How about your Warranty Term?
A: 3-year warranty. we have professional after-sale team to solve your any questions after you placed an order.
And your exclu-sive sales engineer will also help you to get over any problems.
LEDFUL, Makes The World More Colorful.
