Nanyang Mj376as Sawmill China Manufacturing 600mm Sawing Diameter Portable Horizontal Wood Band Saw

Product Description

Nanyang Mj376A (AS)-600 Chainsaw Portable Sawmill China Manufacturing 600mm Sawing Diameter Portable Horizontal Wood Band Saw

Product Description
Horizontal Wood Band Saw
Horizontal band saw machine is a kind of mechanical equipment used to cut various large-sized and long workpieces, such as wood, pipes, etc. The way it works is that the workpiece is placed horizontally on the workbench and then cut by a rotating saw blade. Compared with the vertical band saw machine, the horizontal band saw machine has different working methods and structure, so it has some specific advantages,
Such as wide application range, high efficiency, high cutting precision, good stability, versatility and easy operation, etc. These advantages make horizontal band saws widely used in many industrial fields, especially for processing large-size workpieces.
Product Parameters
Technical Parameters

Item	MJ376A(AS)-600	MJ376A(AS)-900	MJ376/S-900
Max.Sawing Diameter	600mm	900mm	900mm
Max.Sawing Length	4400mm	4400mm	4400mm
Max.Sawing Height	580mm	880mm	880mm
Saw Wheel Diameter	654mm	654mm	720mm
Saw Wheel Width	45mm	95 mm	95mm
Blade Speed:Ordinary Wood Standard Speed	750 r/min	840 r/min	850 r/min
(380V,50Hz,3Phase)Power Output Of Electric Motor	17.2kW or 20.7kW	24.2kW	21.05kW
Main Motor Power	15kW or 18.5kW	22kW	18.5kW
Lifting Motor Power	1.1kW	1.1kW	1.05kW
Forward And BackWard Motor Power	1.1kW	1.1 kW	0.75kW×2
Forward Speed	12m/min	12m/min	12m/mim
BackWard Speed	20m/mim	20m/mim	14m/min
Size Of Saw Blade	5080×80×0.9mm	5830×80×0.9mm	6144×50×0.9mm
Raillength(Standard Model)	5800mm	5800mm	5800mm
Rise &Fall Size	Frequency(or Servo)contro	Frequency(or Servo)control	Servo control
Sawing Control Mode	Automatic	Automatic	Automatic
Dimensions	5800×2300×2200mm	5800×2700×2500mm	5800×2700×2500mm
Weight	2000kg	2500kg	3500kg

Performance Characteristics
1. Use the PLC programming, converter control and digital display control interfaces.
2. Utilize the chain & ball screw to carry out the operation, with high processing precision; have the programmablecontrol function to achieve the stable operation.
3. Own the hydraulic tension system to ensure that the saw blade can be in the best tension state, so as to lengthen the service life of the saw blade.
4. Realize the automatic cooling, lubrication and dust removal system, adopt the one-step mode, and ensure safet
and environmental protection.
5. With high safety performance, the whole sawing process is automatic, safe, reliable and rapid cutting speed
6. It is convenient to assemble, debug, and move with appropriate structure and small covering area
7. It realizes automatic blade grinding and filing with MF115 saw sharpening machine
8. The saw tooth setting machine for general saw blades may achieve the left and right teeth with different saw kerfs.
9. A type is frequency control; AS type is servo control.
Automation Control Panel
1.The console design is simple and intuitive, making it easy to operate.
2.The console is equipped with a variety of function buttons or adjustment devices, which can be adjusted according to different processing needs to improve production efficiency and processing accuracy.
3.The console is equipped with various safety devices to ensure safety.
4.The console is equipped with a display screen and indicator lights, which can display the operating status, parameter settings and other information of the equipment.
High cutting accuracy
The horizontal band saw machine can achieve precise cutting of workpieces, ensuring a smooth cutting surface and accurate cutting dimensions.
Good stability
Since the workpiece is placed horizontally on the workbench, the horizontal band saw machine usually has good stability, which can ensure that the workpiece is not easy to move during the cutting process, improving safety and stability.
Versatility
Horizontal band saw machines usually have multiple cutting functions, which can achieve cutting at different angles and shapes to meet different processing needs.
Cast Iron Saw Wheel
Dynamic Balancing Plus
Work Operation Is More Stable
