New Type Multi-Function Core Displacement Experiment Device

US$23,000.00 1 Set (MOQ)

Basic Info.

Model NO.

ZR-5

Customized

Structure

Desktop

Material

Stainless Steel

Certification

CE, ISO

Application

School, Lab

Type

Separation Type

Zr-5

600

Transport Package

Fumigated Wooden Case

Specification

CE, ISO

Trademark

Sun world

Origin

China

HS Code

84779000

Production Capacity

20 Sets/Month

Product Description

New type Multi-function Core Displacement Experiment Device
This device is mainly for displacement experiments, such as water displacement, chemical flooding, miscible displacement, miscible pressure, CO2 displacement, N2 displacement, natural gas flooding etc.In Oil and gas field development disciplines and research for recovery improvement.The device combined with modern automatic control concepts and humanized structure design and widely used by many oil research institutes.
Main parameters:

Injection pressure	40Mpa
Accuracy	0.2F·S8226S
Flow	0.001ml/min
Hi-pressure Mid-container	1000ml/50Mpa
Low-pressure storage vessel	1000/0.5Mpa
Simulated constant temperature environment	180ºC
Temperature control accuracy	±1ºC
Core holder model	Φ25X80mm
Pressure	32Mpa
Temperature	180ºC
Size	45X45X300mm
Sand feeding model	Φ25X1000mm
Pressure	40Mpa
Vacuum pump	2XZ-25X10-2PA
Vacuum buffer	ZR-5 600ml
Vacuum dryer	ZR-5 600ml
Manual pump	JB-3 50Mpa 210ml
Back-pressure buffer	ZR-2 500ml/32Mpa
Recycle pressure tracker	D-250L 80Mpa 0.8L/Min.
Pneumatic valve	CV210 70Mpa
Storage vessel	ZR-5 3000ml
