Thermoplastic LSZH Fame Retardant Cable Compound with Excellent Thermal Shock Performance

Product Description

Product Description:

This Series of thermoplastic low smoke zero halogen flame retardant polyolefin compounds is made of polyolefin,special type of halogen-free flame retardant and antismoke agent and processed with special formula .
It has good physical and electrical properties, flame retardant properties,excellent extrusion processing performance,non-salivation, low smoke,etc.
It could be used as insulation and sheathing for RF/ low smoke non-halogen cables, communication cables, power cables, control cables, optical cables, telephone signal and data cables which can pass the burning standard IEC 60332-1. Some items also can pass VW-1.

Advantage:

High flame-retarant
Good physical and electrical properties
Low smoke zero halgon non-salivation
Excellent extrusion processing performance
Environmentally friendly
Comply with ROHS&REACH

Application

Item No	Description					Application
RY-EW81015	Thermoplastic low smoke halogen-free flame retardant polyolefin					Apply for sheath of RF/ fiber/ optical cables with small size
RY-EW81206	Thermoplastic low smoke halogen-free flame retardant polyolefin					Apply for sheath of RF/ fiber/ optical cables with small size
RY-KW8002	High speed thermoplastic low smoke halogen-free polyolefin for communication cables					Apply for sheath of Communication UTP,FTP cables
RY-EW82015	General purpose thermoplastic low smoke halogen-free polyolefin for communication cables
RY-EW82016	General purpose high flame retardant thermoplastic low smoke halogen-free polyolefin for communication cables
RY-EW82235	High speed high strength thermoplastic low smoke halogen-free polyolefin for communication cables
RY-EW84016	High flame retardant with level VW-1 thermoplastic low smoke halogen-free polyolefin					Apply for sheath of wires and cables with high flame retardant requirements
RY-EW84215	Low-smoke halogen-free thermoplastic polyolefin for thin-wall cables					Apply for the insulation of wires and cables or sheath of thin-wall cables

Technical Properities:

No	Item		Unit	RY-EW81015	RY-EW81206	RY-KW8002	RY-EW82015	RY-EW82016	RY-EW82235	RY-EW84016	RY-EW84215
1	Density		g/cm3	≤1.53	≤1.53	≤1.45	≤1.50	≤1.53	≤1.53	≤1.53	≤1.53
2	Tensile Strength		MPa	≥10	≥10	≥10	≥10	≥10	≥12.5	≥10	≥10
3	Elongation at Break		%	≥150	≥150	≥150	≥150	≥150	≥180	≥150	≥150
4	Impact Brittleness Temperature(-30ºC)		Piece	Pass	Pass	Pass	Pass	Pass	Pass	Pass	Pass
5	Thermal Aging Performance		ºCxDay	100×7	100×7	100×7	100×7	100×7	100×7	100×7	100×7
	Change Rate of Tensile Strength after Aging		%	≤±25	≤±25	≤±25	≤±25	≤±25	≤±25	≤±25	≤±25
	Change Rate of Elongation at Break after Aging		%	≤±25	≤±25	≤±25	≤±25	≤±25	≤±25	≤±25	≤±25
6	Thermal Deformation(80ºC×6h)		%	≤20	≤20	≤20	≤20	≤20	≤20	≤20	≤20
7	High Temperature Pressure(80ºC)		%	≤35	≤35	---	---	---	---	---	---
8	Volume Resistivity at 20ºC		Ω.m	≥1.0×1012	≥1.0×1012	≥1.0×1012	≥1.0×1012	≥1.0×1012	≥1.0×1012	≥1.0×1012	≥1.0×1012
9	Dielectric Strength		MV/m	≥28	≥28	≥28	≥28	≥28	≥28	≥28	≥28
10	Oxygen Index		%	≥35	≥34	≥30	≥35	≥38	≥36	≥38	≥35
11	Acid Gas
	Conductivity		μs/cm	≤9.8	≤9.8	≤9.8	≤9.8	≤9.8	≤9.8	≤9.8	≤9.8
	PH Value			≥4.3	≥4.3	≥4.3	≥4.3	≥4.3	≥4.3	≥4.3	≥4.3
12	Maximum smoke density	Flame		≤150	≤150	≤150	≤150	≤150	≤150	≤150	≤150
		Flameless		≤300	≤300	≤300	≤300	≤300	≤300	≤300	≤300
13	Toxic Index			≤5	≤5	≤5	≤5	≤5	≤5	≤5	≤5
14	Resistance to Environmental Stress Cracking F0		h	≥96	≥96	---	---	---	≥96	---	---
15	Failure/Total		Piece	0/10	0/10	0/10	0/10	0/10	0/10	0/10	0/10
16	Resistance to cracking			Pass	Pass	---	---	---	Pass	---	---

Package, Transportation and Storage

Package: 25kg per bag, inner PE film and outer kraft paper bag and pallets
Transportation and Storage: Cable materials should not be exposed to the sun and rain during transportation. They should be stored in a clean, cool, dry and ventilated warehouse and also should be handled and carried gently. The shelf life is 6 months.
Ten pallets for a 20'FCL

Company Profile

We,Suzhou Ruiyang Plastic Technology Co., Ltd is a professional manufacturer with 10 years experience in the cable materials in China. We mainly manufacture and supply a series of PVC, LSZH cable materials, special wires &cables materials and cross skeleton etc., which are widely apply for all kinds of cables,such as the communication cables with CMX, CM, CMR, CMP grades ,automotive wires which meet the international standards of the US, Japan, France, and as well as the CL standard of Volkswagen and Porsche and so on. Our company has passed the ISO 9001:2000 quality management system certification . All our products can meet the compliance of ROHS and REACH .The current production capacity is about 2,000,000 kilograms per year.
We own a strong technical research and development team, adhering to the development concept
of "scientific and technological innovation, quality first, customer first" which go all out to
provide customers with good solutions from beginning to end.
We have own IM/EX right, our products with high quality and competitive prices.

Workshop

Test Equipments

Certificate& Test reports

FAQ

1. Are you trading company or Manufacturer ?
We are a professional manufacturer. We are warmly welcome clients from worldwide to visit our factory and cooperate with us.
2.What can you buy from us?
PVC Granules,LSZH granules,Polyethylene,HDPE Granules,LDPE Granules,Cross skeleton, Nucleating agent and other Plastic Granules.
3.Why choose us?
We are a professional manufacturer .We can offer very competitive prices and high quality for all our products.
4.Do you provide samples ? Is it free or extra ?
Yes, We can offer samples below 25kgs, but customers have to bear the shipping cost.
5.How long is your delivery time?
5-10 days. Only when the quantity exceeds 10000kgs delivery time will be agreed by negotiations.
6.Do you accept customization?
Yes,All products can be customized for different requirements.
7.What are your payment terms ?
We'd like to use T/T as the terms of payment. L/C terms can be communicated.
