Rsm1000c Heavy Duty Universal Cylindrical Grinding Machine

Product Description

Such kind of MM-RSM1000C high precision of heavy duty universal cylindrical grinding machine is suitable for external cylindrical grinding of work-pieces up to large grinding diameter. Part of the spare parts is the internal grinding device, increasing the range of applications significantly. A popular model of universal grinder machine for machine construction, mould and tool making and production of industrial series.
Product Description

Heavy Duty Powerful Universal Cylindrical Grinding Machine for Inside and Outside Machining
Main Feature :
Convincing Arguments : Quality, Efficiency and Price
--Max. Grinding Length 1000 mm, Max. Grinding Diameter 320 mm
--Max. Load Work-piece Weight 150 KGS, Center Height 180 mm
--Total Driving Powerful Motor 9000W
--Large machine bed in a heavy design accommodates work-pieces with longer grinding length
--Wide, precision-ground guide-ways ensure maximum accuracy across entire work-piece length and accommodate high work-piece weights
--Proven and extremely rigid machine frame made of premium cast-iron
--Spindle mounted from both sides and features adjustable sliding bearings consisting of 3 segments
--Hydrodynamic bearing of spindle, therefore no contact between spindle and bearing
--Longitudinal table feed set to automatic mode - hydraulically driven or manual mode - by hand-wheel
--Step-less feed adjustments with option of programmable hold time at end of each table movement
--Put grinding headstock into start position manually by hand-wheel or hydraulically
--Hydraulic or manual repositioning of grinding spindle stock
--When conical grinding, the table can be swivelled to either side and exactly positioned by using scale
--Oil film between bearing and spindle keeps vibrations at a minimum level, hence achieving
outstanding results and top accuracy
--Precisely balanced spindle head & solid grinding head make extraordinary results at any operation
--Strong reinforcements and solidly designed panels of the machine base makes it resistant to
temperature fluctuations and deformations
--Longitudinal table guide and cross guide of grinding headstock each feature a V-guide and flat guide
--Certificate of Original (CO, FORM A, FORM E, FORM F)
Product Parameters

Technical Data :

Product Name:	High Precision Universal Cylindrical Grinding Machine
Product Item:	MM-RSM 1000C
Center Height :	180 mm
Grinding Length :	1000 mm
Max. Load Work-piece Weight :	150 KGS
Grinding Diameter :	8-320 mm
Inside Grinding Diameter :	35-100 mm
Inside Grinding Depth :	125 mm
Table Swivel Range (max.) :	-3° to +7°
Table Longitudinal Travel (max.) :	1100 mm
Table Hydraulic Feed :	0.1 - 4 m / min
Table Travel / Hand Turn :	6 mm
Headstock
Work Spindle Speeds :	25-220 RPM (stepless)
Spindle Taper :	MT4
Tilting Range Spindle :	+90 °
Grinding Headstock
Grinding Spindle Speed :	1670 RPM
Speed Inside Grinding Spindle :	10000 RPM
Grinding Wheel Dimensions :	Φ 400 X 50 X Φ 203 mm
Grinding Head Swivel Range :	30°
Travel of Grinding Head :	180 mm
Run-out Deviation :	0.003 mm
Tailstock
Tailstock Taper :	MT4
Travel of Tailstock Sleeve :	30 mm
Motor Power
Motor Rating Grinding :	5.5 KW
Motor Rating Inside Grinding :	1.1 KW
Motor Rating Working Spindle :	1.5 KW
Motor Rating Hydraulic Pump :	0.75 KW
Motor Rating Coolant Pump :	0.125 KW
Total Power Consumption :	9 KW
Gross Weight :	3780 KGS
Packing Size :	3650 X 1850 X 1570 mm
Standard Accessory :	Coolant System 3-Jaw Chuck Wheel Flange Open Rest Machine Light Wheel Balancing Mandrel Grinding Wheel Dresser Internal Grinding Equipment Tools and Toolbox

We are Recognized OEM / ODM manufacturer cooperation with world Famous Germany Machinery Companies for more than 25 years, As a result, Our Team has Prodessional Experience and Innovation Technology to support customers in worldwide. If you want to buy Machine Tools, Welcome to visit our company website to send your enquiry to us, Our team is willing to cooperate with you together.
Our Advantages
Guarantee of Quality
The excellent quality is our dignity. All MAXNOVO MACHINE products are produced with high quality standards.
There are same or similar products on the market, however, those products could not meet the MAXNOVO MACHINE strict quality.
Our products are convincing by outstanding quality, accurate manufacturing and at a cost-efficient price and trustable performance. Well trained quality control department is the first contact for adhering to quality on site.
They are responsible for the dimensional accuracy of the components as well as their control and the quality of the manufacturing process.
A team of quality control engineers directly influences the production process on site by regular training courses and tests.
What is more, they are closing working together with the technical department in the factory.
Due to this intensive care at the production site we are able to achieve literally the MAXNOVO MACHINE. The Metal Scraper Craftsmanship is one of the most important techniques in machine tool industry. To make sure the surface perfectly flat
and smooth, we repeat check and scrap by hand with Time-Proven Unique Techniques that passed on to generations.
At MAXNOVO MACHINE, we strictly enforced that all our contact surfaces must be scrapped with at least 20 spots per square inch
and 40% of contact rate. This can guarantee the True Geometric Accuracy for our high precision machines . Casting is the core of machines, we underscores the importance of its development and production.
At MAXNOVO MACHINE, each casting piece passes various tests, such as high-pressure spray, annealing furnace,
and stress release to assure its stability. This can guarantee all customers with excellent quality of machine parts. The Excellent Quality is our dignity. At MAXNOVO MACHINE, our team is insisting on examining every single part of work-pieces
with strictly high quality standards. In order to fulfill the Large-scale manufacturing requirements in various machine tools, we invested a great deal of resources
and man power in innovating its manufacturing technology. At MAXNOVO MACHINE, the whole machining line is completed
in a temperature-controlled environment so as to maintain this outstanding quality and excellent accuracy.
