Coastal Surveillance Radar / Coastline Surveillance Radar
Basic Info.
Model NO.
CSR501-1C3K
Type
Sensor
Certification
ISO
Application
Communication Electronic Products
Usage
Radar Monitoring, Radar Antenna
Installation Mode
Stationary Installation
Transport Package
Aluminium Alloy Package
Specification
324mm 298mm 86mm
Trademark
WaveSonic
Origin
China
Product Description
Coastal Surveillance Radar CSR 501-1C / C Band CSR 501 -1C provides state-of-the-art protection for the coastline surveillance, boats surveillance management, Anti-boats collision management, Illegal ships surveillance control, and is a C-band working radar, mainly used to detect and track water surface targets, to immediately report the position and coordinate information of targets and quickly make disposal plans for threates. Features -- High data rate and high positioning accuracy -- Multi-Input Multi-Output (MIMO) system -- All-weather adaptability Application Coastline, ports, briges, reservoirs, etc. Specification
| Item | Specification |
| Working mode | Phased array + Pulse Doppler |
| Working frequency | C band (5.5-5.8GHz) |
| Detection range | > 3km (Boats) |
| Minimum detection range | ≤100m |
| Azimuth coverage | Single panel:90° ( Dual panel:180°, 3-panel:270°, 4-panel:360°) |
| Elevation coverage | 18° |
| Distance accuracy | ≤10m |
| Azimuth Accuracy | ≤1.0° |
| Target detection speed | 0.2m/s - 30m/s |
| Speed precision | ≤0.2m/s |
| Data rate | ≤1.5s |
| Net weight | ≤4kg |
| Power supply/Consumption | AC220V/DC12V(External Battery)/65W |
| Interface | Ethernet (UDP protocol) |
| Dimension | 324mm x 298mm x 86mm |
| Working temperature | -40 ºC ~ +60 ºC |
| Working Environment | Rain-proof; Dust Prevention; Sand-prevention; Moisture-proof, Mould-proof and Salt-proof |
