UL/En54 Numens Optical Fire Alarm Smoke Detector

Product Description

SNC-300 non-addressable photoelectric smoke detectors are state-of-the-art detectors suitable for connection to 2-wire or 4-wire non-addressable fire detection control and indicating equipment, or to addressable fire detection control and indicating equipment that can accept non-addressable type detectors.
Advanced electronics in conjunction with a photoelectric smoke sensing chamber provide early detection of fire and high immunity against unwanted alarms.
Features:
· Photoelectric smoke sensor
· Analogue detection discrimination
· Dual LEDs for 360° visibility
· 2-wire and 4-wire models for DC 12 V and DC 24 V operation
· 4-wire model for DC 48 V operation
· 4-wire models available with a N/O alarm relay output
· 4-wire models available with auto-reset
· 2-wire models available with remote LED output
· Connects to zone monitor for use with addressable control and indicating equipment
Specification:

Operating voltage	DC (12/24/48) V
Start-up current	≤ 135 µA
Start-up time	≤ 30 s
Quiescent current	≤ 75 µA
Sampling time	(3 ~ 5) s
Alarm indicator	Dual red LEDs
Remote LED output current (max)	15 mA
Reset voltage	≤ 1 V
Reset time	≤ 5 s
Alarm response threshold	(0.08 ~ 0.15) dB/m
Alarm output relay	SPST. N/O
Operating temperature	(-10 ~ +55) °C
Operating humidity	(0 ~ 95) % RH, non-condensing
Dimensions (excluding contacts)	Φ 102 mm × 45 mm

Ordering Information:

Part Number	2-wire	4-wire	Remote Indicator	Relay Output	Auto-Reset
SNC-300-S2 a	√	-	-	-	-
SNC-300-SL a	√	-	√	-	-
SNC-300-SR a	-	√	-	√	-
SNC-300-SRR a	-	√	-	-	-
SNC-300-SR4	-	√	-	√	-
SNC-300-S2-U b	√	-	-	-	-
SNC-300-SL-U b	√	-	√	-	-
SNC-300-SR-U b	-	√	-	√	-
SNC-300-SA	-	√	-	-	√
