China Factory Wayne Hot Sale High Precision Flat Bed Linear Rail CNC Turning Lathe Machine

Product Description

Product Description
Introducing our premier machine series, where innovation meets elegance. Designed with a sleek, compact profile and an aesthetically pleasing finish, this machine is both visually appealing and exceptionally functional. At its core lies a robust spindle, generating substantial torque for impeccable power. The machine excels in rigidity, ensuring unrivaled stability and reliability, while maintaining extraordinary accuracy over extensive use. With unmatched positional precision and seamless chip evacuation, it is perfect for high-speed, high-precision machining tasks, offering performance like no other. It effortlessly processes inner and outer cylindrical surfaces, cone surfaces, circular arc surfaces, and end faces. Furthermore, it efficiently handles single and multiple threads in metric, inch, and various other standards. This machine is the epitome of efficiency and precision.
Detailed Photos
Product Parameters

SPECIFICATIONS	UNIT	CK6140
Max swingoverbed	mm	∅400
Max swingover cross slide	mm	∅180
Max processing length	mm	750/1000/1500
X/Zaxi;tra-1	mm	x:240 z:750/1000/1500
Spindle speed	rpm	L:70-560 H:200-1600
Spindle nose		C6
Spindle bore	mm	∅52
Spindle taper		MT6
Spindle motor	kw	5.5
Chuck size	mm	∅200
Ball screw dia and pitch		2505/4006
X/Zaxis feed motor torque	N.m	5/7.5
X/Zaxis rapid traverse	m/min	X:6 Z:8
X/Zaxis repeatabilty	mm	±0.005
Processing accuracy		IT6-IT7
Workpiece surface roughness		Ral.6
Tailstock sleeve dia	mm	∅65
Quill traverse	mm	140
Quill taper		MT4
System		GSK
Tool postform		Electric six station
Voltage	v	3 PHASE 380V 50HZ
Machine dimension (L*W*H)	mm	2300*1500*1700
Gross weight	kg	1900

Product Description:
1. Enjoy sheet metal design aesthetics that blend style with ease of use, offering an unparalleled user experience.
2. The bed frame, built from superior resin sand and featuring aging rail super audio quenching, provides exceptional wear resistance.
3. Our advanced rail laminating process significantly enhances wear resistance and extends equipment lifespan.
4. Equipped with a high-precision rolling screw vice transmission, featuring three-point positioning double support for unmatched accuracy.
5. A centralized lubrication unit ensures all moving parts receive comprehensive lubrication, greatly extending the equipment's life.
6. Multiple clamping options are available to suit a diverse range of operational needs.
Fit Range
1. Masterfully capable of turning cylindrical, taper, arc, externality, cut-through, boring, reaming, and crafting various screw threads.
2. Perfect for automotive and mobile parts, valves, electric tools, hardware meters, and more, consistently ensuring surface roughness meets the highest standards.
