ISO Certificate Customized Convenient Operation Belt Conveyor Roller/Idler Making Machine Carbon Steel Pipe Both Ends Flat Head Chamfer Cutting Machine

Product Description

Features of machine tool
Both ends at the same time to complete the center hole, flat head, chamfer, fast and accurate. Can automatically loading and unloading.
The center line of the machining parts and the cutting plate is accurate and unchanged. When the cutting plate is specially designed, the blade is standardized, and the adjustment blade is simple and fast.
PLC control, automatic feeding, automatic clamping, automatic advance and retreat knife, both ends at the same time to ensure length and accuracy.Fast speed, high efficiency.
It is mainly suitable for chamfering of shaft products, removing burr, flat end surface and making center hole.The use of machine chamfering is the development trend of mechanical industry, chamfering machine to overcome the processing shortcomings of mechanical and electric tools, has the advantages of convenient, fast, accurate, is the best choice of axis products chamfer flat head.

Product Parameter

model	TPD-2040
working pressure	4-8Mpa
Processing diameter	Φ20-40mm
Processing length	280-2200mm
working accuracy	±0.1mm
control method	PLC
Dimension (LxWxH)	4115*1200*1400
