China Brand Af88g 88HP Rice Combine Harvester with 2000mm Working Width
Basic Info.
Model NO.
AF88G
Application
Rice
Power Source
Diesel
Harvest method
Vibration fall
Drive Type
Gear Drive
Transmission
Soft Shaft
Portable Harvester Type
Side Hanging Type
Certification
QS, GMP, ISO9001:2008, CE
Color
Choose
Condition
New
Application Field
Agriculture
Warranty
1 Year
Weight
3000kg
Rated Speed(Rpm)
2400
Min Ground Clearance(mm)
325
Working Width(mm)
2050
Rated Power(Kw)
65kw/88HP
Transport Package
Nude Packing
Specification
4850mm*2450mm*2300mm
Trademark
Top Brand
Origin
China
HS Code
8433901000
Production Capacity
50sets/Month
Product Description
Product Description
Combine harvester configured is to efficiently rake, using a raking auger. The ear-tip side part of divider-side grain stems harvested using a cutting blade device, and to prevent damage to the divider. A combine harvester according to the present invention is provided with a divider, a raking reel, a cutting-blade device, a raking auger, a platform, and a conveyor, wherein the combine harvester is characterized in that the raking auger is composed of a cylindrical drum, helical blades projecting from the outer circumferential surface of the drum, and being capable of lateral movement for orienting the grain stems to the conveyor, and a plurality of rod-shaped raking fingers capable of radially extending and retracting from the outer peripheral surface of the drum for guiding the grain stems to the conveyor. At least one of the fingers being provided in a position on the drum aligned within two pitches of receiving blades from the outermost effective receiving blade of the cutting-blade device end section to the inner side in plan view.
Product Parameters
| Full Feeding Combine Hrvester AF88G | |||
| Product Model | AF88G | ||
| Overall dimensions | Length(mm) | 5160 | |
| Width(mm) | 2750 | ||
| Height(mm) | 2750 | ||
| Weight(kg) | 2970 | ||
| Engine | Model | Dachai-DEUT ZCA498Z-09T2/01 | |
| Structure type | Four-stroke,water-cooled, turbocharged diesel engine | ||
| Rated power(kW) | 65/88HP | ||
| Rated speed(rpm) | 2400 | ||
| Fuel type | Diesel(0#) | ||
| Fuel tank(L) | 95 | ||
| Walking part | Track | Specification link | 500*90*51 |
| Min ground clearance(mm) | 325 | ||
| Gearbox type | HST | ||
| Transmission type | (HST+3-gear) continuously variable-speed | ||
| Theoretical traveling speed(km/h) | Low speed 0-3.96,Standard 0-5.14, Walk speed 0-7.37 | ||
| Header system | Header width(mm) | 2000 | |
| Threshing part | Threshing type | Vertical type axial-flow bar tooth type | |
| Threshing cylinder | Outer diameter(mm) | φ620*1790 | |
| Rotate speed(r/min) | 580 | ||
| Grain unloading part | Grain tank capacity(L) | 1400 | |
| Unloading grain rotation range(Degree) | 270 | ||
| Unloading grain height range(mm) | 920-4200 | ||
| Electrolyte and others | Battery | Voltage(V) | 12 |
| Starting relay | Rated current(A) | 50 | |
| Vilotage(V) | 12 | ||
| Hydulic oil tank volume | 21 | ||
| Hourly production(hm2/h)(Vertical dry field crops environment) | 0.3-0.7 | ||
