3D Video of Pipe Tubular and Pressure Vessel Fabication Line

3D Video of Pipe Tubular and Pressure Vessel Fabication Line

US$20,000.00-100,000.00 1 Piece (MOQ)

Basic Info.

Place of Origin
Nanjing
Tube Diameter
up to 4500mm
After-Sales Service Provided
Engineers Available to Service Machinery Overseas
Transport Package
Packed in Container
Specification
ISO9001: 2008
Trademark
NAEC
Origin
China
HS Code
85153190
Production Capacity
200 Sets/Year

Product Description

NAEC---- Lean Fabrication Service Operator for Energy Engineering Industry!
Suitable for industries of: OIL AND GAS, REFINERY FACILITIES, OFFSHORE &SHIPBUILDING, POWER PLANT, ETC.
Reference: CCC, Larsen & Toubro, PEC, Rotary Engineering, Petrol Steel, JSL, Tamimi, AIM, CNPC, SINOPEC, CNOOC, CNCEC, etc.
3D Video of Pipe Tubular and Pressure Vessel Fabication Line
We have 3D video for every solutions, please feel free to contract us for the 3D video.
Features:
1. Pipe spooling fabrication system
2. Tank farm construction ( top-to-bottom)
3.Pipe tubular & pressure vessel fabrication line
4. (Software)Advanced IT System forms a better management system for pipe spool fabirication

Pipe Spool Fabrication Machines
1 Pipe Cutting& Beveling All-in-one Machine
>Suitable for pipes not larger than 8",max.thickness:20mm
>Cutting efficiency:100times/8hrs
>PLC control with automatic measuring to guarantee the same processing cycle
>Widely used for small bore C.S/S.S production lines
2 High Speed Band-saw Cutting Machine
>Three models available(16"type,24"type",48"type)
>PLC system control;self-measuring function with precision:±0.5mm
>Using hydraulic self-centering chuck
>It only takes 6 minutes to cut a 24" pipe of 25mm thickness
>Widely used for C.S/S.S production lines.
3 High Speed CNC Pipe End Beveling Machine
>Automatic self-centering chuck
>Single V,double V,U type bevel
>Can be matched with pipe end turning devic
>High speed beveling:for example,it only takes 2.5minutes to get a 37.5 degree bevel for a S.S pipe end(diameter :610mm,thickness:25mm)
>Several models available:16",24",32",48"
4 Two / Multi- Axis CNC Flame/Plasma Cutting Machine
>High efficient pipe cutting with automatic self-measuring function, pipe end beveling, intersection line profiling for both main and branch pipe.
>Five/multi-axis cutting machine can profile more complicated outlines with various bevel type
>Standard machine suitable for pipes nor larger than 24''
5 Multi-function Pipe Fitting-up Station
>Suitable for flange,elbow,tee,reducer to pipe and special T-joint fitting-up.
>Light-duty type(manual) and heavy-duty type(motorized) are available.
>Different types available, 8" type, 24" type, 32" type, 48" type, 60" type
6 Automatic Pipe Welding Station
>With two welding heads
>TIG/MIG/SAW are optional
>PLC system control & WPS programmed
>Max. efficiency fo reach welding head can be 400D.I/8hrs even use TIG/MIG technology.
>Different types available, 8" type, 24" type, 32" type, 48" type, 60" type
7 Conveyor Handling System
>used for pipe convenient transporation during in pipe spool fabrication.
>Its speed is adjustable between 2M to 20M/min.
For more information, please contact us, thank you!
