HD3605y-25 Professional CNC Lathe with Cylindrical Grinding Machine, Drilling & Milling Ma Technology

Product Description

Featuring box guideways crafted for robust heavy-duty cutting capabilities, offering unmatched stability and precision.
Engineered with a 30-degree slanted, one-piece bed structure that delivers exceptional rigidity for demanding tasks.
Incorporating a stabilized unit structure designed to significantly minimize thermal displacement, ensuring consistent performance.
Offers integrated processing through synchronized control of both main and sub spindles (SY Type), enhancing efficiency.
Experience multi-tasking operations with the wedge type Y-axis BMT turret, optimizing tool handling and versatility.
Achieve an excellent rapid traverse rate at 30m/min along the Z-axis, enhancing operational speed and efficiency.
Ergonomically designed for your convenience, ensuring easy access to both chuck and tool, streamlining your workflow

ITEM			UNIT	HD3605Y
CAPACITY	Swing Over the Bed		mm	940
	Swing Over the Carriage		mm	870
	Max.Turning Dia.		mm	300
	Max.Turning Length		mm	1280
	Bar Capacity	Main	mm	119
		Sub	mm	-
SPINDLE	Chuck Size	Main	inch	12"
		Sub	inch	-
	Spindle Bore	Main	mm	91
		Sub	mm	-
	Spindle Speed	Main	r/min	2,500
		Sub	r/min	-
	Motor(Max/Cont.)	Main	kw(HP)	18.5/15
		Sub	kw(HP)	-
	Torque(Max/Cont.)	Main	N·M	543/440
		Sub	N·M	-
	Spindle Type	Main	-	BELT
		Sub	-	-
	Spindle Nose		-	A2-11
			mm	-
	C-axis Indexing		deg	0.001
FEED	Travel	X/Y	mm	265/120{±60}
		Z/ZB	mm	1350
	Rapid Traverse Rate	X/Y	m/min(ipm)	24/10
		Z/ZB	m/min(ipm)	30
	Slide Type		-	BOX GUIDE
TURRET	No.of Tools		ea	12[24]
	Tool Size	O.D	mm	25[24Tool:20]
		I.D	mm	40
	Indexing Time		sec/step	0.2
	Y-Axis Type		-	WEDGE TYPE
LIVE TOOL	Milling Tool Speed		r/min	4,000
	Motor(Max/Cont.)		kw(HP)	4.5
	Torque(Max/Cont.)		N·M	76
	Collet Size		mm	∅20{ER32)
	Type		-	BMT65P
TAILSTOCK	Taper		-	MT#5
	Quill Dia.		mm	∅100
	Quill Travel		mm	120
	Travel		mm	1350
TANK CAPACITY	Coolant Tank		ℓ(gal)	225
	Lubricating Tank		ℓ(gal)	3
POWERSUPPLY	Electric Power Supply		kVA	35
	Thickness of Power Cable		mm²	Over 25
	Voltage		V/Hz	220/50
MACHINE	Floor Space(LxW)		mm	4,195x1,978
	Height		mm	1,857
	Weight		kg(lb)	7,400
CNC	Controller-		-	FANUC Oi Series

Detailed Photos
ALL-IN-ONE BED DESIGN
OPTIMAL STRUCTURAL ANALYSIS
Our structural analysis enhances the machine's design, increasing tool post body size while reducing height to maintain the bed's dynamic rigidity, even during the most demanding heavy-duty cuts.
The HD-SY Series boasts a 30-degree bed slope, ensuring stable and precise machining at all times.
INTEGRATED COOLANT TANK
Thoughtfully designed with a front-installed coolant tank for optimal convenience, allowing easy chip removal from the machine's right side.
BOX GUIDEWAY
Every axis of the HD-SY Series is meticulously designed with box guideways, ensuring remarkable travel ability and effectively dampening vibrations during heavy-duty cuts.
SEALED GIB STRUCTURE
The X-axis of the HD Series features a sealed GIB structure, designed to protect the turcite from damage caused by chips.
RAPID TRAVERSE RATE (X/Y/Z/ZB)
Achieve rapid traverse rates of 24/10/30/24 m/min with the HD 3605Y/SY, accelerating your production process.
TRAVEL (X/Y/Z/ZB)
The HD 3605Y/SY offers travel dimensions of 265/120/1350/1350 mm, accommodating a wide range of machining tasks.
MILL TURRET
The BMT turret secures tools with four bolts and a key on the mounting surface, providing powerful tool fixation for high precision and reliability.
MILL TOOL HOLDER
Enhanced machining capabilities with straight and angular milling head tool holders allow for versatile operations, including side machining and I.D. operations.
BMT 65P (HD3605Y/SY)
Boasting a speed of 4000 r/min, delivering outstanding performance in high-speed operations.
Compatible with collet size ø20 (ER32), ensuring versatility in tool options.
Achieve quick indexing times at just 0.2 seconds per step, optimizing operational efficiency.
Suzhou Wugan Intelligent Equipment Co., Ltd. is a leader in cutting-edge CNC technology, offering high-performance CNC lathes and turning centers designed with the latest international advancements. Our machines combine high rigidity, precision, and productivity with a sleek aesthetic to deliver superior cutting performance. Meeting the demands of our discerning clients, we offer versatile mill-turn combined models that execute turning, milling, and drilling within a single machine, significantly enhancing output capacity and versatility to satisfy diverse customer needs.
