Slant Bed CNC Lathe Ht3 CNC Turning and Cutting Machine CNC Horizontal Lathe Machine Center

Slant Bed CNC Lathe Ht3 CNC Turning and Cutting Machine CNC Horizontal Lathe Machine Center

US$46,500.00
1-2 Sets
US$45,000.00
3+ Sets

Basic Info.

Model NO.
HT3
Type
Turret Lathe
Processing Accessory
Chuck CNC Lathe
Guide Rail
Inclined Guide Rail
Tool Holder
Single-tool Holder CNC Lathe
Power Source
Hydraulic Pressure
Controlling Mode
CNC
Automatic Grade
Automatic
Setting Mode
Floor-type
Precision
High Precision
Certification
CE
Condition
New
Turning Lathe
CNC Metal Mini Turning Lathe
CNC Turning Lathe
Turning Lathe CNC
Mini Turning Lathe CNC
Mini Turning Lathe
45 Degree CNC Inclined Bed Lathe
Germany Metal Automatic CNC Lathe
CNC Lathe
CNC Slant Bed Lathe
Year
2023
Transport Package
Packing in Seaworthy Wooden Cases
Specification
Dimension(L*W*H): 3600 /1850 /1800 mm
Trademark
DRC
Origin
China
Production Capacity
500

Product Description

High-Precision Slant Bed Turret Small CNC Turning Center 3-axis Lathe
MachineWith 12-station Power Turret For Metalworking
IHT series Tuning Lathe machine with FANUC control system, Included Standard Equipment and Standard Control System
Functions.
Integrally molded low center of gravity casting bed, 30 ° saddle through optimized design, It has a large shock damping and
a smaller
amount of deformation, the main axle box, turret. Providing high-rigidity structure basis. 30 ° slant bed design to facilitate the
operator
upper and lower parts, but also to ensure. Smooth chip evacuation.
( More Detailed Picture of IHT series CNC Lathe Machine )
Small CNC turning and milling turret lathe machine with C axis live tool
1.Super Rigidity Lathe
The Lathe machine structure is integrated into a strong base,lower barycenter, 30° saddle desigh to achieve better vibration
damping and reduce deformation, providing headstock & turret with a very stable base.30° slant bed structure, more convenient
for bar loading& unloading, smoother for chip removal.
2.Modern Popular Control Packages Lathe
iHT series Lathe have optional FAUNC 0iTF control package &Siemens 828D control package, 8.4' display, 10.4' display,extra
interfaces etc. ready for customers.
3.Super Cost Performance Lathe
German lineage iHT Series Lathe boast best components, such as SAUTER turret, NSK bearings etc. to gurantee the high
precision performance. Meanwhile we offer competitive price to make iHT series super high cost performance.
4.User-friendly Design Lathe
Minimal space occupation but mostly compliant to the actual work area, full protective enclosure with human aesthetic design,
stainless telescopes cover, provide safe & clean working environment and better durability.
5.Abundant Options Lathe
Electric turret, servo turret, powered turret, upgrade spindle power, upgrade spindle torque, upgrade bore of cylinder & chuck,
drawer type coolant tank, tool probe, oil-mist seperator etc. options ready for customers.
6.iHT Series technology:
High stability and perfect machining results thanks to the integrally molded massive HT300 cast iron bed.
The bigger spindle bearings and the appropriate wide spacing between the guideway ensure that iHT series machines by high
accuracy and rigidity.
Slot disk, vDl disk, BMT disk, electric turret, servo turret, servo-driven turret all can choose by the customer.
Hydraulic controlled tailstock, servo tailstock all can choose.
Inner housing made by the stainless steel which can avoid to rust.
Hollow chuck as standard (Closed center chuck optional)
Traversable steady rest (HT10 optional
Product Parameters
Machine Parameters
IHT316S
Spindle head: FL 140 h5
Max. Torque: 112 N/M
Spindle maximum speed: 6000 rpm
FANUC Spindle power:7.5/11KW
Spindle bore: 74mm
Chuck diameter: 165mm
Front bearing diameter: 100mm
Speed range: 5-6000rpm
Maximum swing over bed: 558mm
Center distance: 608mm
Maximum cutting diameter: 328mm
Maximum cutting length: 310mm
Maximum bar capacity: 42mm
Travel Z: 380mm
X/Z axis ballscrew D/P: Oct-32mm
Travel X: 180mm
Rapid traverse Z/X: 30/30m/min
Feed force X/Z: 4500N/M
X/Z axis measuring system: Absolute rotative
Number of axies: 2
VDI/DGQ 3441 Positioning (X / Z): 0.008/0.008mm
VDI/DGQ 3441 Repeatability (X / Z): 0.004/0.005mm
No. of tool stations Driven tools: 12
Power turret: SAUTER
Tool attachment: VDI 30
OD tool size: 20 mm
Driven tool holder type: 30 / W16/0,8/30/18 DIN 5480 VDI
Maximum clamping force: 3000 N
Maximum speed: 3000 rpm
Driven power: 3 KW
FANUC Torque: 20 N/M
Frequency: 50 ± 1% Hz
Voltage: 380 ±10% V
Max. installed power: 25 KVA
400v lie protection fuses: 50A
Connection cables section: 4/10 mm2
Max. working pressure: 55bar
Reservoir capacity: 35 l
Pump flow: 24 I/ min
Pump delivery: 30 l /min
Capacity with tank: 100 l
Pump pressure : 5 bar
Less than: ≤80 dB (A)
FANUC Control system :0iTF
Slant angle, Material:45°, HT300
Net weight :3200 kg
Floor Space Requirement- with conveyor :
3600/1850/1800 mm
