AC-360V Three-Phase 10kw H-Type Vertical Axis Wind Power Turbine

Product Description

AC-360V Three-Phase 10KW H-Type Vertical Axis Wind Power Turbine
Suitable for any Application; Urban to Rural, Residential to Commercial, Industrial to Institutional
Over speed Protection & Braking System
Governed Speed Style Aerodynamic Pitch Control
Brake Style Automatic Mechanical Brake
Advantages of VAWT
1. Nearly Quiet
2. More Safety
3. Captures Wind From Any Direction
4. Birds Friendly
5. Longer Working Life
6. Less Maintenance
7. Less Requirements on Foundation
8. Lower Supporting Tower
Features
1. VAWTs are better able to harvest turbulent air flow found around buildings and other structures
2. VAWTs are ideal for both rural and urban applications, including roof top installations. Depending
On the shape of the roof, the wind flow over the roof can be concentrated, leading to an increased
Energy output
3. Simple to install and maintain
Technial Parameter:

Model	SHJ-VH10K
Rated power	10000W
Max power	12000W
Rated voltage	360v
Start-up speed	2.5m/s
Rated wind speed	10m/s
Survival wind speed	35m/s
Top NW	1015kg
Wheel diameter	5.2m
Number of blades	5
Blades material	Reinforced glass fiber
generator	Three phase ac permanent magnet generator
Control system	Electronic magnet
lubrication	Lubrication grease
Working temperature	-40 °C -80 °C

H-Type Vertical Axis Wind Turbine Main Components
1. Q: Is installation easy?
A: Yes, very easy. Every customer can do it by themselves. We supply you all the components and the isntallation manual.
2. Q: Is our wind enough for a wind generator?
A: Our wind generator can start running at low wind speed 3m/s, so if your average annual wind speed is more than 5m/s, it can works well.
3. Q: Which model should I choose?
A: If you are not sure to choose the model, please contact our sales with the following points:
1. What appliance do you want to run by the system? How much watts are they? How long do they work?
2. Your average annual wind speed.
3. What kind of system do you want? On-grid or off grid?
4. Q: Can I only buy parts of the whole system?
A: Yes, you can only buy wind turbine, controller, inverter etc.
Our service
1. We can design different systems of wind turbine for customers according to your requirements. For example, on-grid or off-grid, solar and wind hybrid system or solar wind diesel generator system.
2. All long-term technical support and parts cost supply.
3. 24 hours on-line---Your enquiries will be replied within 24 hours.
Project Cases:
