3.5kw 3.8kw 3500W 3800W Portable Open Frame Type Gasoline Inverter Generator

Product Description

Overview
Inverter technology for clean power, THD<3% ,Economy system, electronic speed control function, fuel costs can be saved. 32kgs, light and portable,Parallel Operation FunctionProduct
Product Parameters

Specification
Model	IG4500
Frequency	50Hz/60Hz
Rated power	3.5KW
Max. power	3.8KW
AC voltage	110V,120V,220V,230V(based on destination country requirement)
Fuel capacity(L)	10
Run Time(50%-80% load)	11~6.5 hrs
Engine Model	UP170CA
Engine Type	Four-stroke, Air-cooled, OHV gasoline engine
Displacement Capacity(cc)	223
Start system	Recoil
Noise @7m	72
inverter	IGBT controller
Speed(adjustment range)	2600rpm ~ 3600rpm
THD	<3%
Unit Dim( L x W x H )(mm)	492x402x477
Packing Dim( L x W x H )(mm)	542x452x532
Net Weight/Gross Weight(kg)	30/ 32
Loading Q'ty(20GP/40GP/40HQ)	200/416/416

Detailed PhotosKey Compnents
Product Dimension
Control panel details Certifications
Company Profile
United Power Equipment Co.,Ltd is founded in 2003,we design, develop, manufacture and sell an extensive range of engine-driven power equipment, including generators, water pumps,high pressure washer and engines. Our major products comprise residential as well as commercial generators which are currently delivered to more than 45 countries in the world. Relevant markets are the domestic market (China) and overseas markets, in particular the Europe and North America.
Our factory is located in Fuzhou,Fujian Province,a beautiful city in Southeast China,the area is 120,000 sqm and total staffs are over 500.I believe we have the capability to live up to your high standards.
Packaging & Shipping
Both brown cartons and color box are available,we have a department to help you finish your design for the carton which makes your products look nicer.
Our service
Support for Product Development
If you want to develop a new model,our technical department will provide a full supports to you with our 14 years experience in this industry.
OEM
If you want to develop your own brand, We will provide OEM service from very aspects you need.
Best After-Sales Support As a company with 17 years history,we already meet any problems that may happen on generators,so our after-sales support is very professional.
FAQ
1.Q:Are you a manufacturer or trading company?
A: We are a manufacturer.2.Q: Where is your factory located ?
A: Our factory located in Gaoqi Industry Zone,Minhou, Fuzhou, China. 3.Q: How does your factory take the quality control ?
A: Our QC Department take the strictly quality control for every spare parts and whole machine.
4.Q: Can you do OEM or ODM?
A: We do both.
5.Q: How about your delivery time?
A: 35 days for container order and sample order. The specific delivery time depends on the items and the quantity of your order.
