Advanced Eco-Friendly Foam Machines for Sustainable Packaging Solutions

Product Description

ps foam sheet extruder machine
The ps foam sheet extruder is the first step to make the final products ,so it is so important for starting .
we are professional in the ps foam sheet area in China , and also with rich experience in customer requirement .our main market is the
south of America , welcome to talk with us and visit our factory .
Machine Features: -Precise designed screw
-With precise extrusion elements
-Special designed rear part of secondary extruder to guarantee no leakage
-Cooling water of secondary extruder controlled by computer to ensure better cooling -Distinctive die and air ring guarantee even thickness and sheet quality -Can memorize all technical parameters
Model parameters Unit HLSJPS-100/130
Capacity kg/hr 250-310
Thickness mm 1.5-6
Sheet width mm single sheet 800-1500
Foam rate times 11-30
Density kg/m3 32.5-90
L/D 36/1,33/1
Cooling Air cooling for primary extruder ,water cooling for second extruder
Liner speed m/min 5-30
Central height mm 1100
Cooling water pressure Mpa ≥0.2
Cooling water volume t/h 13
Compressed air pressure Mpa 0.7
Compressed air volume m3/min 1.1
Butane gas pressure Mpa 1
Installed power kw 250
Installed size m 33x4.5x3
Weight t 18
