230cm Air Jet Weaving Machine for Medical Gauze Bandage
| US$11,000.00-15,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
JLH425S
Computerized
Computerized
Precision
High Precision
Certification
CE, ISO9001: 2000
Warranty
1 Year
Customized
Customized
Condition
New
Reed Width
190cm-340cm
Shedding
Plain
Heald Frame
2PCS/Set
Electronic Weft Feeder
Single Nozzle/Double Nozzle
Let-off
Mechanical/Electronic
Take-up
Mechanical/Electronic
Yarn Scope
7s-80s
Max Warp Density
80 Ends Per Inch
Max Weft Density
60 Pick Per Inch
Transport Package
Export Packing
Specification
ISO
Trademark
JLH
Origin
Shandong China
HS Code
8446305000
Production Capacity
300 Sets/ Per Month
Product Description
JLH425S medical gauze weaving machine in best sell :
Features and main technical parameters
JLH425-1model air jet loom with high quality weaving, running stable, low noise low energy ,save labor ,width range of yam count ,low maintenance cost.
Product purpose
JLH425-1 model air jet loom is that we designed and developed a special high speed machine suit for low weft density weaving features .it's a best machine for medical gauze ,tyre fabrics, glial cotton ,dalrib, leather base cloth .
Advantages
JLH425-1model air jet loom with a width range of weave ,one loom can weave 1pc, 2pcs or 3 pcs except medical gauze but also can weave general fabric ,leather base fabric ,yam-dyed fabric and industrial fabric and so on ,the most reed width can reach to 340cm.
Reed width | 135cm,150cm,170cm,190cm,210cm,230cm,260cm,280cm,320cm,340cm,360cm |
| feeder | electronic feeder |
| nozzle | single nozzle,double nozzle |
| shedding | plain/cam/dobby |
| frame | 2pcs/4pcs/6pcs or more |
| Let-off | Mechanical/Electronic | ||||
| Take-up | Mechanical/Electronic | ||||
| Cloth roller | Normal/jumbo package | ||||
| Edge | Selvage edge/tuck-in selvage | ||||
| Gauze fabric type (1pc or 2pc or 3pc at same time) | Cotton yarn count (S) | Warp & Weft density (pick per inch) | Gauze width (inch) | Production (m/day) | |
| 40 x 40 | 26x18 | 36"-134" | 730-1200 | ||
| 40 x 40 | 16x14 | 36"-134" | 940-1530 | ||
| 32 x 32 | 31 x21 | 36"-134" | 620-1020 | ||
| 10 x 10 | 40 x20 | 36"-108" | 650-900 | ||
We are TOP 1 manufcturer of gauze product making machinery in china , not only gauze weaving machine we are available , but also the whole gauze prodction line we can supply : including warping machine,bleaching machine,gauze machine.
