Nt320 Plastic Injection Molding Machine Added Infrared Heating Coil and Servo Motor System for Manufacturing Industry
| US$37,500.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
NT320
Type
Preform Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Plunger Type
Clamping Way
Hydraulic
Automation
Automatic
Computerized
Computerized
Certification
ISO9001:2008
Marketing Type
Hot Product
Core Component
Motor, PLC
Material
Stainless Steel
Applicable Industrial
Manufacturing Plant
Voltage
380V/50Hz 3p+N+E(Alterable)
Function
Plastic Parts Production
Mold
Can Be Customizable
Clamp Force
3200kN
Space Between Tie Bars
660*625
Transport Package
at Seller′s Option
Specification
6.45m*1.65m*2.35m
Trademark
Leantall
Origin
China
Production Capacity
20sets/Month
Product Description
Product Parameters| Part | Name | Unit | NT320 | ||
| Injection Unit | SCREW DIAMETER | mm | 60 | 65 | 70 |
| SCREW L/D RATIO | L/D | 21.6 | 20 | 18.5 | |
| INJECTION STROKE | mm | 300 | 300 | 300 | |
| NJECTION SPEED | Mm/sec | 107 | 107 | 107 | |
| SHOT VOLUME(THEORETICAL) | CM3 | 848 | 995 | 1154 | |
| INJECTION WEIGHT(PS) | g | 771 | 905 | 1050 | |
| INJECTION PRESSURE | Mpa | 176 | 150 | 129 | |
| INJECTION RATE | cm³/sec | 302 | 355 | 412 | |
| SCREW SPEED | rpm | 180 | |||
| Clamping Unit | CLAMP FORCE | Kn | 3200 | ||
| OPEN STROKE | mm | 620 | |||
| SPACE BETWEEN TIE BARS | mm×mm | 660X625 | |||
| MAX.MOULD HEIGHT | mm | 630 | |||
| MIN.MOULD HEIGHT | mm | 230 | |||
| EJECTOR STROKE | mm | 160 | |||
| EJECTOR FORCE | Kn | 101 | |||
| EJECTOR NUMBER | N | 13 | |||
| Others | MAX.PUMP PRESSURE | Mpa | 16 | ||
| SEVRO DRIVE POWER | Kw | 39 | |||
| HEATING POWER | Kw | 18.5 | |||
| MACHINE DIMENSION(L*W*H) | m×m×m | 6.45*1.65*2.35 | |||
| MACHINE WEIGHT(ESTIMATE) | T | 9 | |||
Product Description
Packaging & Shipping
Company Profile
Our Advantages
Q: Are you manufacturer or trading company? A: We are manufacturer with decades experiences,located in Zhejiang province. Q: What is the product range? A: Focus on the manufacture and development of plastic injection molding machines and its auxiliary equipment such as cooling tower, chiller, etc. Q: Where is your main selling market? A: We have business domestic,USA,Russia,Indonesia,Egypt,Turkey ,Uzbekistan, Pakistan,etc. Q: Will you offer field installation and operator training at the buyer's factory? A: Yes,we will arrange our skilled engineers for filed installation and training. Q: What is the delivery time(equipment production time)? A: It will be ready around 50 days after getting mutual confirmation about the order details and prepayment. Q: Do you also have source for molds and spare parts? A: Yes,we can offer with the competitive quality and reasonable price. Customized as required. Q: What is the standard of package? A: Wooden case packing for the auxiliary equipment, bare packing for the plastic injection molding machine. Full container shipment is highly suggest.
