Kemapower SVC 3 Phase Automatic Voltage Stabilizers 50kVA Voltage Stabilizer 380V AC
| US$430.00-1,205.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
SVC3 1.5-90K
Frequency Characteristics
Intermediate Frequency
Usage
SVC
Frequency
Industrial Frequency
Size
Large
Iron Core Shape
Ring
Power Source
Switching Regulated Power Supply
Application Range
Scientific Research Department
Brand
Kemapower
Transport Package
Seaworthy Packing
Specification
1.5-90KVA
Trademark
KEMAPOWER
Origin
China
HS Code
8507600090
Production Capacity
50000PCS/Yer
Product Description
Three Phase Servo Motor Automatic Voltage RegularSVC3 1.5-90K
KEY FEATURES Three phase Servo motor automatic Voltage Regular 1.5KVA-90KVA Input 3P+N+G=380V or 3P+G=220V Output 3P+N+G=380+-3% or 3P+G=220V±3% PF 0.8, Terminal Overload , short Circuit over-voltage, low voltage etc Voltage regulating speed 10V/S LED + Dial display,or LCD display Option TECHNICAL SPECIFICATIONS
| Input Voltage Range | Default 3P+N+G= 260V-430V or 3P+G=150- 264; Option 3P+N+G= 160-430V | ||||
| Output Voltage | Default 3P+N+G=380V or 3P+G=220V | ||||
| Stabilization Accuracy | Default 3P+N+G=380V ±3 % or 3P+G= 220V±3% | ||||
| Frequency | 50Hz / 60Hz | ||||
| Wave Form Distortion | No addictive wave form distortion | ||||
| Efficiency | >90% | ||||
| Debug Time | <1s (With the input voltage variation of 10%) | ||||
| Over Voltage Protection | Default Phase Voltage 246V±4V or 130V ±4V | ||||
| Ambient Temperature | from -10 to +40ºC | ||||
| Temperature Rise | Lower than 60ºC | ||||
| Overload Power Factor | 0.8 | ||||
| Dielectric strength | 1500V/min | ||||
| Insulation resistance | 2MΩ | ||||
| Protection | overload , short Circuit over-voltage, low voltage etc. | ||||
| Display | LED + Dial instrument display,or LCD display Option | ||||
| Model | Capacity | Product Size (mm) | G.W (kg) | Packing Size (m) | Unit/CTN |
| SVC3-1.5K | 1.5KVA/1.2KW | 480*320*165 | 14 | 0.57*0.41*0.255 | 1 |
| SVC3-3K | 3KVA/2.4KW | 480*320*165 | 17 | 0.57*0.41*0.255 | 1 |
| SVC3-4.5K | 4.5KVA/3.6KW | 480*320*165 | 18 | 0.57*0.41*0.255 | 1 |
| SVC3-6K | 6KVA/4.8KW | 305*275*670 | 30 | 0.375*0.345*0.745 | 1 |
| SVC3-9K | 9KVA/7.2KW | 325*315*770 | 38 | 0.395*0.385*0.85 | 1 |
| SVC3-15K | 15KVA/9.6KW | 425*370*830 | 90 | 0.5*0.45*0.91 | 1 |
| SVC3-20K | 20KVA/16KW | 415*460*895 | 100 | 0.545*0.505*0.985 | 1 |
| SVC3-30K | 30KVA/24KW | 415*460*895 | 108 | 0.545*0.505*0.985 | 1 |
| SVC3-40K | 40KVA/32KW | 415*460*895 | 120 | 0.545*0.505*0.985 | 1 |
| SVC3-50K | 50KVA/40KW | 450*550*1160 | 155 | 0.55*0.64*1.13 | 1 |
| SVC3-60K | 60KVA/48KW | 450*550*1160 | 162 | 0.55*0.64*1.13 | 1 |
| SVC3-75K | 75KVA/60KW | 620*510*1350 | 200 | 0.695*0.595*1.515 | 1 |
| SVC3-90K | 90KVA/72KW | 620*510*1350 | 215 | 0.695*0.595*1.515 | 1 |
PRODUCT DISPLAY
Input voltage and output power
