Automatic Drain Valve For16- 40 Bar

Product Description

Timer auto drain valve for compressed air:
Specifications
Automatic electronic drain valve for air compressor
Automatic drain valve
-guarantee period: 1year
-Prevents rusting
Automatic electronic drain valve for air compressor
High quality, low cost
One kind of model suits all applications, simple installment,
Completely
Description: High Quality integrated electric drain valve / electric valve / brass valve
The electronic drain valve is a full-feature automatic electronic solenoid drain valve that cost-effectively removes condensate from compressors, receivers, dryers, aftercoolers, filters and drip legs.

Valve	MIC-A/B
Species	Two two straight valve
In / out interface size	1/2 "3/8" or 1/4"
The maximum working pressure	16Bar;40Bar;60Bar;80Bar
Minimum / maximum ambient temperature	2°C/55°C
The maximum temperature of the medium	90°C
The valve body	Forging brass, flow aperture 5.0mm (all stainless steel valve can special order)
Insulation	Heat group H
Protection grade	IP65
Voltage	24-230V AC/DC(voltage 380VAC can special order)
Voltage range	+/-10%
Installation position	Arbitrarily

FAQ:
Q1: Could you help us to recommend the model for our project?
A1: Yes, we have engineer to check the details and choose the correct model for you. Based on the following: Cooling capacity; If you don't know, you can offer the flow rate to your machine, temperature in and temperature out from your using part; Environment temperature; Refrigerant type, R22, R407c or other, pls clarify; Voltage; Application industry; Pump flow and pressure requirements; Any other special requirements.
Q2: How to ensure your product with good quality?
A2: All our products with CE certificate and our company Strictly comply with ISO900 quality management system. We use the worldwide famous brand accessories. The units will be fully tested before package and The packing will be carefully checked.
Q3: What's the warranty?
A3: 1 year warranty for all parts; Whole life labor free!
Q4: Are you a manufacturer?
A4: Yes, we have more than 23 years in industrial refrigeration business. Our factory located in Shenzhen; Welcome to visit us at anytime. Also have patent on the chillers' design.
