Plastic HDPE Pet Bottle Cocacola Bottle Crushing Washing Dewatering Recycling Machine

Product Description

Retech Plastic PET Bottle Cocacola Bottle Crushing Washing Dewatering Recycling Machine

Product Description
Retech Plastic PET bottle Cocacola bottle washing recycling line is used to recycle post-consumer PET bottles, water bottles, cola bottles, PET sheet and PET packing containers.
The key point of PET recycling system is the rate of removing the impurities.The higher purity PET flakes will improve the end product and lower the manufacturing cost of next processing.We could design different PET recycling solutions basis on the requirement of standards on final flakes.
Nowadays, our PET washing line have been exported to many countries & regions, e. G. Latin-America, Mideast, Russia & MID-Asia, Africa, etc.
PET washing line/PET bottle washing line/PET flake washing line (including crushing, washing, drying)
This line consist of plastic select device, crusher, washing tank, separate, dryer and packing. This is the whole complete line on our project.
Condition of final PET flake for PET washing line:
Moisture: Not more than 1.0%
PVC Content: Not more than 200ppm
Metal Content: Not more than 20ppm
Label, ring and caps Content (i. e. PE, PP): Not more than 240ppm
Total amount: Not more than 560ppm

Product capacity	300kg /h	500kg /h	1000kg /h	1500kg /h
Workshop(L*W*H)	40m *7.5m*6m	42m *10m*6m	70m *12m*6m	75m *15m*6m
Needed worker	3-4 persons	5-6persons	7-8persons	10-12persons
Water supply (recycle use)	2-3ton/h	3-5ton/h	7-10ton/h	10-15ton/h
Final product quality	Moisture: Max 1% Bulk density: 0.3G/CM 3 Particle size: 10-18mm Metal content: Max. 20ppm Floatable contamination: Less than 200ppm Total impurity: 100-320ppm

Consideration for our customer ,we will design different line for our customer:
1, We provide different capacity for our customer: 200kg/h, 300kg/h, 500kg/h, 1000kg/h,1500kg/h,2000kg/h,2200kg/h,2500kg/h.
2, According to your material, you may choose different device.
3, According to your country condition, you may choose full automatic line or semi-automatic line.
4, Our customer may purchase device based on his own condition.
5, Based on your workshop condition, our design always matched to your workshop mostly.
Machine List Components of Pet Bottle Washing Line:
Label Remover machine---Sorting system---PET Crusher machine---Flakes Floating washing tank---Hot Washing system,---Frication washing system---dewatering machinery and fin dust label separator machine---hot air drying system and the Packing system

Application for PET washing line:
This recycling line is composed of garbage separation (automatic & manual), bottle & flake crushing, cold & hot washing & cleaning, flake dewatering & drying, dust & label removal, packing, etc.
Main Fetures

Feasture for PET washing line:
1. High automation level, try best to reduce your cost on labor (especially for three shifts) and ensure high processing capacity: 150-2000kg/hr
2. Friendly control system (PLC integrated & separated control on each machine) and Touch screen panel, easy for operation, monitor and emergency stop.
3. All parts contacting with plastic material and water are made of high-quality 304 or 316 stainless steel; Ensure no second pollution to flakes.
4. Ideal impurity removal effect. Here is from our customer's feedback.


Basic Production Process


Certifications

Our Advantages

our advantages:
1. Recycled material: Total impurity content ≤320PPM, Moisture content≤2%. 2. Production Capacity: 300-3500Kg/h3. Plan design according to Customers' requirements.4. Simple design, user-friendly operation.5. Lower investment cost for a high quality and durable machine.6. Low energy consumption, High output capacity.7. Usual delivery time: 60 days.8. Engineers are available to do commissioning work abroad.
Service
Our Service:
1.Pre-sale support
Retech Machinery consists of experienced specialists, we will offer a suitable solution according client's requirement in time.
2. After-sale service
Retech 's skilled technicians are available to assist with onsite installation, commissioning & training on request. This will enable customers to optimize the performance of their new plant. Customers will be briefed on all aspects relating to operation and maintenance by a Retech technician. Dimensional drawings together with service requirements will be provided prior to delivery of the equipment. This will allow the customer to prepare the site and allow them to commence production in a timely fashion.
Retech holds a adequately inventory of spare parts and their efficient service personnel will ensure that any required part will be dispatched without delay. Delivery of the spare parts may be by air, sea or courier depending on the urgency of the situation. Customers are encouraged to hold their own critical spare parts such as granulator blades and screens to ensure optimal machine condition and performance.
3. Technical support
Retech plastic washing and recycling machinery provides enough hardware resource especially for large-scale production lines, clients can carry out installation, commissioning and acceptance before delivery.
