Lty-2000 Plastic Injection Molding Machine for Thermoplastic
| US$28,000.00 | 1 SET (MOQ) |
Basic Info.
Model NO.
LTY-2000
Type
Plastic Product Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008, GMP, QS
Transport Package
Wrap Film Packing Into The Container
Specification
200T
Trademark
LOYALTY
Origin
China
HS Code
8477101090
Production Capacity
1000sets/Years
Product Description
| SPECIFICATION | LTY2000 | ||||
| A | B | C | D | ||
| INJECTION UNIT | |||||
| SCREW DIAMETER | mm | 45 | 50 | 55 | |
| SCREW L/D RATIO | L/D | 24.5 | 22 | 20 | |
| SHOT VOLUME(THEORETICAL) | cm3 | 340 | 420 | 510 | |
| INJECTION WEIGHT(PS) | g | 310 | 383 | 466 | |
| INJECTION RATE | g/s | 124 | 154 | 186 | |
| INJECTION PRESSURE | MPa | 210 | 168 | 140 | |
| SCREW SPEED | rpm | 155 | |||
| CLAMPING UNIT | |||||
| CLAMP FORCE | KN | 2000 | |||
| OPEN STROKE | mm | 475 | |||
| SPACE BETWEEN TIE BARS(W*H) | mm | 530x530 | |||
| MAX.MOULD HEIGHT | mm | 530 | |||
| MIN.MOULD HEIGHT | mm | 200 | |||
| EJECTOR STROKE | mm | 140 | |||
| EJECTOR FORCE | KN | 70 | |||
| OTHER | |||||
| MAX.PUMP PRESSURE | MPa | 16 | |||
| PUMP MOTOR POWER | kW | 18.5 | |||
| HEATING POWER | kW | 13.6 | |||
| MACHINE DIMENSION(L*W*H) | m | 5.92x1.55x2.14 | |||
| OILTANK CUBAGE | L | 300 | |||
| MACHINE WEIGHT | t | 7.3 | |||
