Small Scale Ring Spining Machine

Product Description

Product Description
Product DescriptionAT286 Small Scale Ring Spinning MachineAT286 Small Scale Ring Spinning Machine is part of the mini spinning system (including opener, carding machine, drawing frame, roving machine, ring spinning machine and winding machine) which is widely used in universities, researching center and small scale production, it can be used for both cotton, wool and blend fiber. AT286 Mini Scale Ring Spinning Machine is used to spin yarn from roving by ring spinning method.SpecificationModelAT286Number of spindles75, 96, 108, 156, 372, 396Spindle gauge75mmRingΦ51*11.2Lift230mmCount50~12.5tex (20~80Nm)Draft ratio12~40Twist range50~250twists/meterDraft typeThree-roller, double aprons, pendulum weight armsBottom roller dia35mmBottom roller gaugeFront-mid105105105110Front - behind263223, 230223230Spindle speed4500 ~ 13000rpmTwist directionZ or S, settablePower supply3 phase AC380V 50HzDetails and Features1 Mini machine, save researching cost and easy to operate and maintain;2 Touch screen & PLC control;3 Friendly human-machine interface, inputting of technical parameters and display of machine running status by touch screen;4 Frequency converter of high efficiency to control roll speed;5 Pressurizing system :spring pressure cradle;6 Three-up-three-down drafting structure;7 Optional special program for spinning slub yarn on this ring spinning machine; Our CompanyPacking&DeliveryPackage Packaging Details1. The equipment is covered with film is protect it from water vapour during the trip.2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated.PaymentPayment Term T/TEXW 30% T/T in advance, paid the balance before shipmentFOBCFR(C&F) 30% T/T in advance, paid the balance against copy of B/LCIFL/CL/C amount above 50,000 usd, we can accept L/C at sightWest UnionAmount lower than 5000usdDelivery Time7~10days after receiving payment for one containerContecting Us
