U560V-PVC Injection Blow Molding Making Machine/Production Line
| US$10,000.00-400,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
U560V
Plastic Type
Thermoplastic, Tube Head Injection
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Screw Type
80,85,90mm
Distance Between Tie Bars(Width)(mm)
830 mm
Ejector Force
150kn
Ejector Force(Kn)
150 Kn
Open Stroke(mm)
850 mm
Oiltank Cubage
795 L
Screw Speed (Rpm)
0 - 80 Rpm, 80
Key Selling Points
High-Accuracy
After Warranty Service
Video Technical Support, Online Support
Theoretical Shot Volume(Cm3)
2212 Cm3
Injection Rate (G/S)
620 G/S
Distance Between Tie Bars
830*830
Screw L/D Ratio
22, 22,20.7,19.6,17.6
Plastic Processed
PVC, FRPP/PVC
Screw Diameter (mm)
80 mm
Specification
New
Trademark
AOTAI
Origin
Zhejiang, China
Production Capacity
500 Set/Sets Per Year
Product Description
U560V-PVC Injection Blow Molding Making Machine/Production LineProduct Description
Specification
| Machine model | U560V-PVC | ||
| Screw type | A | B | C |
| Screw diameter (mm) | 80 | 85 | 90 |
| Screw L/D ratio (L/D) | 22 | 20.7 | 19.6 |
| Shot volume (theoretical) (CM3) | 2212 | 2497 | 2799 |
| Injection weight (PVC) (g) | 2818 | 3181 | 3566 |
| Pump max.pressure (Mpa) | 16 | ||
| Pump motor power (servo)(KW) | 55(58) | ||
| Number of heating area(Segment) | 5+1 | ||
| Machine dimension (L*W*H) (M) | 8.45*2.15*2.84 | ||
1. What kind of plastic material can be used on this machine?
PP, PE, PS, ABS and other general material could be used on this machine.
If you have other special material such as PC, PMMA, PVC, please contact us for further information. 2. What is guarantee time for this machine?
12 months after installation or 18 months again B/L date.
3. What kind of shipping container for this machine?
Containere choose will depends on the different machine size . 20HQ,40HQ,40GP will suitable for different size machine.
4. How much is Engineer service charge?
We can send experienced technician to customer's country for guiding the installation and commission the machine, also train the
customer's employee. Customer need to afford technician visa charge, round trip air ticket expense, accommodation and
transportation in local. Also customer needs to pay USD 80 per days to technician as salary.
5. How long will be for installation and commission this machine?
If customer prepare all necessary thing such as power supply, water supply, hydraulic oil, plastic material, plastic mold,
installation and commission period will be within 7days including training customer's employee.
6. How many workers are needed to operate this machine?
One worker only.
7. What is the power consumption for this machine?
Power consumption is determined by the product. Different product requests different power consumption.
