New Type Laminating Paper Cup Base Kraft Paper Slitting Rewinding Machine

Product Description

Plastic lamination machine a3 Paper roll laminating machine Features of woven bag laminating machine: 1. The extruder adopts automatic temperature control, and automatic material suction and the die head adopts the proprietary die head of the proprietary manufacturer.
2. The unwinding part, compound part, and rewinding part of the unit are automatically tensioned and synchronized.
3. The rewinding part adopts an automatic device to realize a large coil diameter and high rotation speed without stopping the coil change, and will not stop the machine and waste. Fourth, the unit frequency conversion speed regulation, PLC man-machine interface operation, and linkage control.
4. The unit is equipped with a corona treatment machine, automatic deviation correction machine, finished product meter, adjustable edge trimming, and edge suction device.
5. The equipment has a novel structure, beautiful appearance, quick installation, and convenient operation. 1. The principle of laminating machine Extrusion tape casting: plastic particles are plasticized by a screw and then extruded from a flat die in a linear shape. After stretching, they are attached to the surface of flexible substrates such as paper, film, non-woven fabric, and woven cloth. It is a composite material that combines the barrier properties and heats sealing properties of the plastic film layer, the strength and toughness of the substrate, and functional properties. 2. Composition of laminating machine The whole machine is composed of a feeding device, extruder host, die, unwinding mechanism, compounding mechanism, winding mechanism, edge position control device, trimming device, heating and cooling system, electrical measurement and control system and other parts. According to the needs of different products, the second unwinding mechanism, printing equipment, oven, substrate surface treatment device (corona machine, etc.), online thickness gauge and other components can be added. Pre-process equipment: granulator, printing press or other equipment; post-process equipment: slitting machine or other equipment. Equipment List

Machine Composition
Model	Machine	Quantity
1	Double station unwinding system	1 set
2	Vacuum screw feeder	1 set
3	Hopper dryer	1 set
4	Single screw extruder	1 set
5	Single board single station filter	1 set
6	Solution static mixer	1 set
7	Laminating Special Mould	1 set
8	Laminating composite molding system	1 set
9	Online Infrared Detection System	1 set
10	Correction device	1 set
11	Fabric static elimination device	1 set
12	Tractor	1 set
13	Double station automatic winding system	1 set
14	interface control system	1 set

Product Overview Our Company Zhengzhou Shuliy Machinery Co., Ltd. was founded in 2000. Our company specializes mainly produce plastic processing machines. We not only provide customers with cost-effective products but also provides first-class service support and solutions. Our products have been exported to countries and regions such as Arabia, India, Russia, Central Asia, Africa, and Mongolia. The perfect after-sales service system allows you to be worry-free. FAQ Q1: Are you a manufacturer or a trading company?
A1:We are a professional manufacturer of producing machinery for over 10 years.
Q2: How is the quality of your product?
A2: Our products are manufactured according to national and international standards, and we have a test on every machine before
delivery.
Q3: How about the price?
A3: We are a professional manufacturer and be able to provide you with the lowest price than the market one. We will give you the best
quotation.
Q4:What if the machine is damaged?
A5:One year warranty and all-around after-sales service. After this deadline, we shall charge at a low cost to keep after-sales
service.
