WiFi6 Standard 5g Wireless Router Support Poe, 2*2 MIMO Technology, with 4 Gigabit LAN Ports
| US$285.50 | 100 Pieces (MOQ) |
Basic Info.
Model NO.
AX1750T
Transfer Rate
2500Mbps in Wan Port
Firewall
Firewall
Ports
5
Port Structure
Modular
Application
Enterprise, SOHO
Network
4G/5g, DSL Network
Performance
Non Line Speed Router
Architecture
Single Bus Master-slave CPU
USB
Yes
Chipset
Qualcomm
WiFi Standard
11ax
WiFi Frequency
2.4G +5.8g
WiFi Data Rate
1800Mbps
Poe
Support
GPS
Avalible If Need
Transport Package
Brown Box, Can Be Customized
Specification
25.7*21.3*5.5 CM
Trademark
Yuncore
Origin
China
HS Code
8517629900
Production Capacity
100000/Month
Product Description
WiFi6 standard 5G wireless router support PoE,2*2 MIMO technology,With 4 gigabit LAN portsProduct Description This is an WiFi6 standard 5G wireless router support PoE .
Equipped with IPQ6010 chipset, it comply with 802.11ax, 2*2 MIMO technology, dual band, up to 1800Mbps data rate; With 10/100/1000/2500Mbps WAN port, it can work as an wireless PoE router, to provide more upload/download throughput to meet with the demand of high flow.
It is an 4G/5G wireless router with PoE out function, With 4 gigabit LAN ports, all ports can provide 48V PoE out, can provide 5G data and PoE for CCTV, Car or other special applications.
With skypworks high power PA, the RF power up to 23dBm, equipped with external MIMO antennas, easy to achieve long range wireless coverage with better wireless signal and more stable wireless experience.
It with QSDK driver, support seamless roaming, 5G prior, OFDMA and DL/UL-OFDMA (37 users in 5.8G, 18 users in 2.4G); What's more, this device can work with OpenWRT firmware also, our technical firmware team can provide efficient technical support for fast firmware development.
| Hardware | |
| Chipset | IPQ6010+5022+5052+QCA8081+QCA8075 |
| Standard | 802.11ax/ac/b/g/n |
| DDR | 256MB(16bit)*2=1GB, maxi up to 2GB |
| Flash | NOR-8MB AND NAND-128MB |
| 2.4G Frequency | 2.4GHz - 2.484GHz |
| 2.4G Wi-Fi standard | 802.11b/g/n |
| 5.8G Frequency | 5150~5850MHz |
| 5.8G Wi-Fi Standard | 802.11 ax/ac |
| Interface/ | 1 * 10/100 /1000/2500Mbps RJ45 WAN Port (WAN port support 24~48V passive in if need, but if WAN port support PoE in, LAN ports can't support PoE out) |
| 4 * 10/100 / 1000Mbps RJ45 LAN Ports(Support 48V active PoE out if powered by DC) | |
| 1 * Reset | |
| 1 * SIM card slot support 4G/5G, M.2 interface | |
| 1 * Bluetooth (Optional with extra cost) | |
| 1 * USB3.0 Port | |
| 1 * SD Card Slot | |
| 1 * Type C USB | |
| 1 * DC Port, support 12~48V DC | |
| Antenna | IPEX Connector, 4*5dBi omni WiFi antennas 1*Bluetooth antenna (Optional with extra cost) 4*4G/5G antenna 1*GPS antenna |
| Data Rate | 1800Mbps ( 2.4G: 591Mbps (11ax 2x2); 5.8G: 1238Mbps (11ax 2x2)) |
| End Users | 150+ |
| RF Power | 2.4g ≤ 24dBm 5.8g ≤ 24dBm |
| DC | 12V~48V |
| PoE | WAN: 48V Passive PoE in LAN: 48V active PoE out |
| LED light | Sys; 5.8G wifi; 2.4G wifi; WAN; LAN, 5G; 4G, GPS |
| Max Power Consumption | ≤ 60W |
| Size | TBD |
| Weight | TBD |
| Working Temperature | -20°C to 45°C |
| Storage Temperature | 0°C to 70°C |
| Humidity | 5%~95% (non-condensing) |
