Heavy-Duty Hydraulic Wing Disc Harrow
| US$11,300.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
1BZDZ-4.4
Power Source
Tractor
Traction Type
Tractor
Drive Type
Tractor
Color
at The Instance of
Transport Package
Customers Requirement
Specification
many
Trademark
dadi
Origin
Shan Dong China
Production Capacity
20000
Product Description
Heavy-duty hydraulic wing disc harrow1BZDZ series wing-folded heavy-duty disc harrow are mainly used for cleaning away stubble of plants before tillage or crushing clods after tillage on uncultivated land and in sticky heavy clay soil fields they can also be used as a plough for primary tillage in dry cultivated fields. The series produced are all fitted with hydraulic rubber wheel for transportation
It is easy to be transported and change direction on the edge of fields.
Specifications:
Technical parameters:
| Model | Unit | 1BZDZ-4.4 | 1BZDZ-4.8 | 1BZDZ-5.3 | 1BZDZ-6.2 |
| Overall dimension | mm | 5800×4500×1500 | 5800×4950×1500 | 5800×5400×1500 | 5800×6380×1500 |
| Weight | kg | 3100~3150 | 3250~3300 | 3400~3450 | 4150-4200 |
| Working width | m | 4.4 | 4.8 | 5.3 | 6.2 |
| Working depth | 240 | ||||
| Blade spacing | mm | 230 | |||
| No of disc | pc | 40 | 44 | 48 | 56 |
| Dia.of disc | mm | 660 | |||
| Transport clearance | mm | >260 | |||
| Productivity | ha/h | 2.7 | 3.2 | 3.8 | 4.65 |
| Matched power | HP | 105-110 | 115-120 | 125-130 | 140-160 |
| Linkage | Trailed | ||||
