Metallographic Upright Microscope for Laboratory Using
| US$1,000.00-8,000.00 | 1 set (MOQ) |
Basic Info.
Model NO.
ER-600
Number of Cylinder
≥Three
Mobility
Desktop
Stereoscopic Effect
Without Stereoscopic Effect
Kind of Light Source
Ordinary Light
Shape
Cylindrical Shaped Lens
Usage
Teaching & Research & Quality Control Labs
Principle
Optics
Principle of Optics
Polarizing Microscope
Nosepiece
Five-Hole Brightfield Converter
Optical System
Infinity Chromatic Aberration Correction
Focus
Coaxial Coarse and Fine Focusing
Stage
230X215mm
Polarizing Kit
Polarizer Insert Plate, Fixed Analyzer Insert Plat
Focusing
12V100W Halogen Lamp
Transport Package
Carton Box
Specification
10X eyepiece, 5/10/20/50X objective lens
Trademark
EBP
Origin
Zhejiang, China
HS Code
9011800090
Production Capacity
300 Sets Per Month
Product Description
Overview:All operations of ER-600 are designed according to ergonomics to minimize operator fatigue. Its modular component design allows for free combination of system functions. Covering a variety of observation functions such as bright field, dark field, oblique illumination, polarization, DIC differential interference, etc., the functions can be selected according to the actual application.
Technical parameters:
| part | Specification |
| Optical system | Infinity chromatic aberration correction optical system |
| Observation tube | 30° tilt, inverted image, infinity hinged three-way observation tube, interpupillary distance adjustment: 50-76mm, three-speed split ratio 0:100; 20:80; 100:0 |
| Eyepiece | PL10X/22mm |
| Objective lens | 5X, 10X, 20X, 50X (Optional 40X, 100X) |
| Nose piece | Internally positioned five-hole brightfield converter with DIC slot |
| Focusing rack | Transparent and reflective frame, front low hand position coarse and micro coaxial focusing mechanism. The coarse adjustment stroke is 33mm, and the fine adjustment accuracy is 0.001mm. It has an adjustable elastic device to prevent sliding and a random upper limit device. It has a built-in 100-240V wide voltage system, 12V100W halogen lamp, transmitted light lighting system, and the upper and lower lights are independently controllable. |
| Stage | 4" double-layer mechanical mobile platform, platform area 230X215mm, stroke 105x 105mm, with glass platform, right-hand X and Y moving handwheel, equipped with platform interface |
| Lighting system | Bright and dark field reflection illuminator, with variable aperture diaphragm, field diaphragm, center adjustable; with bright and dark field lighting switching device; with color filter slot and polarizing device slot |
| Polarizing accessories | Polarizer insert plate, fixed analyzer insert plate, 360° rotating analyzer insert plate. |
| Metallographic analysis software | FMIA2023 version metallographic analysis system, 12-megapixel Sony chip camera device USB3.0, 0.5X adapter mirror interface, high-precision micrometer. |
