Fully Automatic 1000 Liter/Hour Ultrafiltration Membrane System Equipment

Product Description

Different Water TDS(Total Dissolved Solids)compare and usuage
Raw water /Application	Bottled water ,Bag water	City tap water	Brackish water	Sea water
TDS Range	2-10ppm	100-1000ppm	2000-20000ppm	20000-40000ppm
Direct Drinking	YES	YES/NO	NO	NO
Cooking,Human Consumption Washing	YES	YES/NO	NO	NO
Lrrigation,Industry, Animal Drinking	YES	YES	NO	NO

Product Description What' s reverse osmosis system? Reverse osmosis is the most advanced and effective desalting technology. The principle is that under the higher pressure more than the dissolved solution osmotic pressure. Only follow water molecules through the reverse osmosis membrane. Then the solute and solvent separated, thereby getting the purified water. The fine particles, colloid, organic matter,bacteria, virus and 99%the dissolved salt can be removed by the water quality stability etc. already widely used in electronic, electrical,food and other fields. What's the working principle of the RO membrane for the reverse osmosis system? The spiral membrane is constructed of one or more membrane envelopes wound around a perforated central tube. The permeate passes
through the membrane into the envelope and spirals inward to the central tube for collection. Working process of RO system:
Raw water pump→ mechanical filter→ activated carbon filter→ sodium-ion exchanger→ precision filter→
high pressure pump →Reverse osmosis→ Ozone sterilizer (UV). 1. Raw water pump-- provide the pressure to quartz sand filter/active carbon filter/softener.
2. Multi-medium filter--get rid of turbidity, suspended matter, organic matter, colloid, etc.
3. Active Carbon filter--Remove the color, smell, free chloride, organic matter, harmful matter, etc.
4. Softener--exchange "ions" of calcium and magnesium with the most common and easiest method.
5. Security filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um,
6. High pressure pump--Provide the high pressure to RO membrane.
7. RO system-- main part of the plant. The RO membrane's desalting rate can reach 99%, removing over 99% ions. Application Our products are widely used in food, beverage, electroplating, electronics, optics, chemicals, semiconductors, cosmetics, thermal power plants, metallurgy, light industry, automobile manufacturing, medical treatment, industrial water and other fields. Company Profile Guangzhou Qingyouqing Water Treatment Equipment Co., Ltd. is a water purification equipment production and manufacturing factory, the production base is located in Guangzhou Nansha District, the main production of industrial, household, commercial water purification equipment. The company mainly engaged in hospitals, laboratories, electronics, chemical, food, mining, optics, glass and other complete sets of professional pure water equipment. The company wholesale and retail :RO reverse osmosis drinking water equipment, EDI ultra-pure water equipment, UF ultrafiltration water purification equipment, groundwater water purification equipment, water softening equipment, etc., to provide cheap, practical and affordable water purification treatment products. Certifications FAQ
