High Temperature/Pressure Oil-Water Relative Permeability Reaction Device

Product Description

High Temperature/pressure Oil-water Relative Permeability Reaction Device
1. Determination of relative permeability of two phases (oil-water, gas-liquid) and three phases (oil, gas, water) by steady-state method or unsteady method;
2. Enhanced oil recovery studies, such as secondary and tertiary oil recovery, polymer injection, ternary oil injection, miscible flooding test;
3. Formation sensitivity (formation damage) assessment, study of foreign substances in drilling, completion, water injection, stimulation and workover operations, formation damage and methods to avoid or mitigate damage;
4. Research on oil production technology, such as acidification, fracturing, water plugging, adjustment of injection-production profile, etc.;
5. Joint test experiment, that is, test the relative permeability of the same rock sample, measure its resistivity and automatically calculate its saturation;
6. Permeability measurement.
High temperature and high pressure oil-water relative permeability reaction device technical indicators:

Ring crush Pressure	60 Mpa
Displacement pressure	0 ~ 50MPa
Operating temperature	≤150ºC±1ºC
Applicable core	φ25.4×25 ~ 80
Displacement flow	0-10 mL /min

Note: This device can be customized.
