Hot-Transfer Decals Rotary Glass Screen Printing Machine Jb-1020A
| US$1,000.00-100,000.00 | 1 SET (MOQ) |
Basic Info.
Model NO.
JB-1020A
Color & Page
Single-Colour Printing Press
System Supported
3p 380V 50Hz 14.64kw
Weight
5500kg
Measurement
15.07cbm
Package
2 Plywood Case
Plate
Screen Printing
Model
1020X720mm
Usage
Label Printer, Cloths Printer, Paper Printer
Automatic Grade
Automatic
Printing Speed
3000PCS/H
Transport Package
Plywood Cases
Specification
1020x720mm
Trademark
JINBAO
Origin
Made in China
HS Code
8443192900
Production Capacity
200sets/Year
Product Description
Hot-Transfer Decals Rotary Glass Screen Printing Machine JB-1020A Product Description JB-A Series full automatic stop cylinder screen press which adopts the classical stop cylinder technology with the advantages such as: Paper located exactly and steadily, high precision, high speed, low noise, high degree auto matizaton and so on, it is suitable for printing on ceramic and glass applique, electron industry (film switch, flexible circuitry, meter panel, mobile telephone), packing and printing, brand, textile transfer, special technics etc. Product Parameters| Model | JB-720A | JB-800A | JB=1020A |
| Max. paper dimension | 720X520m | 800X610m | 1020X720m |
| Min. paper dimension | 350X270m | 350X270m | 560X350m |
| Max. printing dimension | 720X500m | 800X600m | 1020X710m |
| Paper thicknes | 108-400g\ | 108-400g\ | 120-400g\ |
| Border | ≤ 10mm | ≤ 10mm | ≤ 10mm |
| Max. printing speed | 1000-3600pcs\h | 1000-3300pcs\h | 1000-3000pcs\h |
| Power | 3p 380v 50Hz 8.89KW | 3p 380v 50Hz 8.89KW | 3p 380v 50Hz 14.64KW |
| Weight(about) | 3500kg | 4000kg | 5000kg |
| Overall dimensions | 4050X2240X1680mm | 4350X2580X1680mm | 4650X2800X1680mm |
