Kmd-80100 Engraving and Milling Machine

Product Description

KMD-80100 Engraving And Milling Machine Product Description
Great engraving and milling machine adopts a high-rigidity fixed beam gantry structure. The body is made of high-grade resin sand castings. The internal stress is eliminated through artificial aging treatment to prevent the deformation of the machine tool. The main functional components are all well-known manufacturers or imported brands, such as: Taiwan ball screw, linear guide, Japanese servo motor. Ensure that the machine tool has high precision and stable operation. Suitable for automotive industry, home appliance industry, injection mold, hardware mold, engraving mold industry, such as: automobile tires, car lamp molds, copper (graphite) electrodes, shoe molds, pen molds, toy molds, hardware molds, hot stamping molds, high frequency Molds, can process various metals such as copper, iron, steel, aluminum, graphite, plexiglass, wood and other materials.
Gantry structure: bridge and column integral casting, multi-rib, box-shaped structure, integral processing and forming, no vibration during high-speed cutting, improving processing accuracy and surface finish of workpiece.
Axial motor direct connection: The three-axis axial motor and the ball screw adopt a direct connection design, with a transmission efficiency of 100%, no belt transmission, fast servo response speed, and high processing accuracy.
Rotatable control panel: For machine operators who work for a long time, whether it is to calibrate tools or monitor machine and program conditions during processing, the rotary control panel can greatly improve the comfort during operation, reduce fatigue, and improve workplace safety Sex and productivity.
High-speed electric spindle: 18000~30000 rpm motor with built-in spindle, allowing deep processing of tools with higher slender ratio. In particular, it can be easily completed for clear corner machining with a very small radius, or high-precision cutting that directly replaces electrical discharge machining.
Workbench full stroke support: The workbench is completely placed on the base, full stroke support, five overhangs, and high accuracy. Detailed Photos

Product Parameters

Items	Unit	KMD-650/ KMD-650S	KMD-7080/KMD-7080S	KMD-80100	KMD-10100
Working desk size	mm	500×600	800×600	820×1020	1000×1000
X, Y, Z axis working stroke	mm	600×500×250	700×800×330	820×1000×350	1100×1000×550
Maximum load-bearing capacity of worktable	kg	300	400	900	1000
Distance from spindle end to worktable	mm	100-350	100-430	100-390	50-550
Spindle taper	/	ER25/ ER32	ER25/ ER32	ER32	BT40
Spindle speed	/	18000/24000	18000/24000	18000	15000
Spindle power	kw	5.5	7.5	7.5	7.5
X, Y, Z axis rapid feed	m/min	12	12	18	18
X, Y, Z axis cutting feed	m/min	8	8	10	10
Positioning accuracy	mm	±0.005	±0.005	±0.005	±0.005
Repeatability	mm	±0.003	±0.003	±0.003	±0.003
Gatepost width	mm	760	760	900	1100
Operating voltage	v	380V/50HZ	380V/50HZ	380V/50HZ	380V/50HZ
CNC system	/	Taiwan Syntec	Taiwan Syntec	Taiwan Syntec	Taiwan Syntection
Machine weight	kg	3200	4000	6400	7500

Company Profile
Ningbo GREAT Machine Tool Co., Ltd. is a modern scientific and technological enterprise specializing in the production of CNC Machinewith brand name Great. Our company is in the Baojia Industrial Park of Ningbo City, adjacent to the airport, highway, railway station, and bus station with very convenient transportation.Our main products including: Vertical machining centers, high-speed drilling and tapping machines, CNC engraving and milling machines, gantry machining centers, horizontal machining centers, etc. Complete specifications, diversified configurations can be selected according to your different needs. We offer customized products according to your needs, cost-efficient products processing solution, importing automation, replacing labour by machines, etc.Our products are suitable for producing auto accessories, textile Accessories, digital products, medical instruments, mold manufacturing, aluminum casting and so on.We import inspection equipment from Italy and Britain and conduct complete inspection for each machine, including machine tool geometry inspection, laser interference inspection, full tool test, spindle motor dynamic balance correction, etc. To ensure the high precise and stable quality of our products. In addition, we provide best after-sales service. Our professional teams maintain close contact with customers and provide technical support at any time if necessary.We adhere to the Diamond quality concep tand keep working on it to provide best products for each customer.
