Vertical Milling Machine X5032 X5036 X5040
| US$4,000.00-6,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
X5032 X5036 X5040
Type
Knee-and-Column Milling Machine
Object
Tool
Structure
Desktop
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Overall Welding Tooth
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
High Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Drill Capacity
25mm
Motor
2.2kw
Max Tapping Dia(mm)
M16
Table Size
1250X320mm
Taper
ISO40
Transport Package
Plywood Case
Specification
185kgs
Trademark
HOYONG-TRD
Origin
Shandong, China
HS Code
84595900
Production Capacity
10 PCS/Month
Product Description
VERTICAL MILLING MACHINE FEATURES:
Model X5032 Vertical Knee-type Milling Machine, has extra travel in longitudinal, operating control adopts a cantilever panel. It is suit for milling flat,
inclined face, angular surface, slots by employing disc cutters, angular cutters. When mounted with the index, the machine will be able to perform milling
operations in gears, cutter, helix groove, cam and tub wheel.
Vertical milling head can be swiveled by ± 45° . Spindle quill can be moved in vertical. The longitudinal, cross and vertical movements of the table can
both be operated by hand and power, and it can be rapid moved. Working table and slide ways adopted quality cast hardened ensure high accuracy.
| SPECIFICATION | UNIT | X5032 | X5032B |
| Table size | mm | 320X1325 | 320X1600 |
| T-slots (NO./Width /Pitch) | 3/18/70 | 3/18/70 | |
| Longitudinal travel (manual/auto) | mm | 700/680 | 900/880 |
| Cross travel (manual/auto) | mm | 255/240 | 255/240 |
| Vertical travel (manual/auto) | mm | 350/330 | 350/330 |
| Rapid feed speed | mm/min | 2300/1540/770 | 2300/1540/770 |
| Spindle bore | mm | 29 | 29 |
| Spindle taper | 7:24 ISO50 | 7:24 ISO50 | |
| Spindle speed range | r/min | 30~1500 | 30~1500 |
| Spindle speed step | steps | 18 | 18 |
| Spindle travel | mm | 70 | 70 |
| Max.swivel angle of vertical milling head | ±45° | ±45° | |
| Distance between spindle nose and table surface | mm | 60-410 | 60-410 |
| Distance between spindle axis and column guide way | mm | 350 | 350 |
| Feed motor power | kw | 2.2 | 2.2 |
| Main motor Power | kw | 7.5 | 7.5 |
| Overall dimensions(L×W×H) | mm | 2294×1770 ×1904 | 2294×1770 ×1904 |
| Net weight | kg | 2900/3200 | 2900/3200 |
