High Efficiency 37m Concrete Pump Truck Sy5230thbf 370c-10 on Sale
Basic Info.
Model NO.
SY5230THBF 370C-10
Type
Concrete Pump
Shotcrete Type
Semi-Dry
Machining Process
Hydraulic
Structure
Cylinder Type
Productivity
120m²/h
Condition
New
Color
Red
Keywords
Concrete Machinery
Name
Concrete Pump Truck
Boom Vertical Height
32.2m
Boom Horizontal Length
28.2m
Application
All
Brand
China Top Brand
Pressure
9.6MPa
Conveying Cylinder Stroke
1400mm
Chassis Model
Sym5210thb1f
Engine Maximum Net Power
191/2200kw/Rpm
Transport Package
Bulk
Specification
23000KG
Trademark
Top Brand
Origin
Anhui, China
Production Capacity
500000units/Year
Packaging & Delivery
Package Size
1028.00cm * 253.00cm * 385.00cm
Package Gross Weight
23000.000kg
Product Description
High Efficiency 37m Concrete Pump Truck SY5230THBF 370C-10 on Sale
The SY5230THBF 370C-10 A features a compact and ergonomic design, with dimensions of 10280mm in length, 2530mm in width, and 3850mm in height. This makes it easy to maneuver and operate, even in tight spaces. The pump truck also boasts a gross weight of 23,000 kilograms, ensuring stability and durability during operation.
In terms of certifications, the SY5230THBF 370C-10A is compliant with CE and ISO9001 standards, guaranteeing its quality and safety. It is sold as a single item and comes with a packaging size of 10280cm x 2530cm.
With a vertical maximum reach of 36.5 meters and a horizontal extension capability of 31.8 meters, the SY5230THBF 370C-10A offers impressive outreach, making it ideal for a wide range of applications, including high-rise building construction, bridge projects, and other large-scale infrastructure developments.
Product Parameters
| Model | Unit | SY5230THBF 370C-10 | ||
| Overall Specification | Length | mm | 10280 | |
| Width | mm | 2530 | ||
| Height | mm | 3850 | ||
| Dead Weight | kg | 23000 | ||
| Boom & Outrigger Specification | Vertical Reach | m | 36.5 | |
| Horizontal Reach | m | 31.8 | ||
| Reach Depth | m | 24.8 | ||
| Min. Unfolded Reach | m | 7.5 | ||
| 1st Section | Length | mm | 7550 | |
| Articulation | ° | 89° | ||
| 2nd Section | Length | mm | 6025 | |
| Articulation | ° | 180° | ||
| 3rd Section | Length | mm | 5835 | |
| Articulation | ° | 180° | ||
| 4th Section | Length | mm | 6660 | |
| Articulation | ° | 230° | ||
| 5th Section | Length | mm | 6355 | |
| Articulation | ° | 180° | ||
| Rotation | ° | ±360° | ||
| Front Outrigger Spread L-R | mm | 6110 | ||
| Rear Outrigger Spread L-R | mm | 8500 | ||
| Pumping System Specification | Output | Low-Pressure | m³/h | 120 |
| High-Pressure | m³/h | 70 | ||
| Pressure | Low-Pressure | MPa | 8 | |
| High-Pressure | MPa | 13 | ||
| Delivery Cylinder Diameter | mm | 230 | ||
| Stroke Length | mm | 1600 | ||
| Hydraulic System | | Open | ||
| Hydraulic System Oil Pressure | MPa | 32 | ||
| Oil Tank Capacity | L | 320 | ||
| Water Tank Capacity | L | 700 | ||
| Pipe Diameter | mm | 125 | ||
| End Hose Length | m | 3 | ||
| End Hose Diameter | mm | 125 | ||
| Chassis Specification | Chassis Brand | | top brand | |
| Chassis Model | | SYM5230THB1F | ||
| Engine Type | | D09C6-320E0 | ||
| Engine Maximum Net Power | kW/rpm | 229/1900 | ||
| Emission Standard | | China stage VI | ||
| Fuel Tank Capacity | L | 300 | ||
| Displacement | L | 8.7 | ||
| Max. Speed | km/h | 90 | ||
