Pet Dog Accessories Collar Shoe Making Machine Shoe Eyelet Machine

Product Description

Model	BD-98A
Power of motor	0.95kW
Package size	777×1092×1530mm
Net weight	250kg
Gross weight	290kg
Maximum width of materials	<= 50mm

USE
This machine is mainly used for riveting for shoe eyelets in single-row or multi-row of all kinds of fabric belts and leather belts.
CHARCTERS
1. Adopt PLC and touch screen control, display fault detection automatically. It's easy to maintain and user-friendly to operate.
2. Automatic punching, feeding and riveting eyelets can be completed at one time.
3.Multiple riveting modes are available: single row, multiple rows, custom mode and segment mode.
a. Single row and multiple-row mode: fill in the X and Y axis data to rivet eyelet in tape or leather belt;
b. Custom mode: after the distance required for each eyelet is programmed, the eyelet can be riveted;
c. Segment mode: for the entire fabric belt or leather belt, after programming required data and riveting, it can clip by segments.
