Dispersing Power Mixing Machine Qlf-1100L PU and Polyurethane Sealant Silicone Sealant

Product Description

1. CHARACTERS
1) Dispersing power mixing
2) High speed
3) Vacuum, cooling and heating function
4) No dead point
5) Suitable for PU sealant, RTV sealant, HTV sealant, Acrylic sealant
6) CN, ISO9001
2. SUMMARY
QLF dispersing power mixer is a kind of high-efficiency multifunctional mixer already proved by practice. It can meet the needs of users to quickly change working requirements during operation, and can custom-make various kinds of mixer to meet different viscosity materials on clients' requirements. Working capacity range from 5L to 3500L, power is designed according to viscosity of materials. It is widely used in silicone sealant, adhesive, cosmetics, chemical products, battery, foodstuff, pharmacy and plastic industries, etc. Dispersing power mixer has 3-4 different stirrers inside of vessel, including one low-speed stirrer revolving around vessel axis, and the other 2-3 high-speed stirrers rotating around its own axis at different high speeds to achieve complicated movement of strong shearing and kneading for materials inside of vessel.
The E-shaped scraper inside the equipment revolves around the vessel axis to scrape the materials adhering to wall and bottom for ideal mixing effects. The equipment is well sealed, can be vacuumized, with excellent exhaust and bubble removal effects. The vessel cover can be hydraulically lifted, and vessel body can move freely for ease of operation.

MODEL	NOMINAL CAPACITY	VACUUM DEGREE	VESSEL TYPE	DISCHARGE MODE
QLF-5L	5L	-0.098MPa	Electric, steam, oil heating / oil, water cooling jacket	Plug / No neck valve
QLF-10L	10L	-0.098MPa	Electric, steam, oil heating / oil, water cooling jacket	Plug / No neck valve
QLF-20L	20L	-0.098MPa	Electric, steam, oil heating / oil, water cooling jacket	Plug / No neck valve
QLF-50L	50L	-0.098MPa	Electric, steam, oil heating / oil, water cooling jacket	Plug / No neck valve
QLF-100L	100L	-0.098MPa	Electric, steam, oil heating / oil, water cooling jacket	Plug / No neck valve
QLF-200L	200L	-0.098MPa	Electric, steam, oil heating / oil, water cooling jacket	Plug / No neck valve
QLF-300L	300L	-0.098MPa	Electric, steam, oil heating / oil, water cooling jacket	Plug / No neck valve
QLF-600L	600L	-0.098MPa	Electric, steam, oil heating / oil, water cooling jacket	Plug / No neck valve
QLF-1100L	1100L	-0.098MPa	Electric, steam, oil heating / oil, water cooling jacket	Plug / No neck valve
QLF-1500L	1500L	-0.098MPa	Electric, steam, oil heating / oil, water cooling jacket	Plug / No neck valve
QLF-2000L	2000L	-0.098MPa	Electric, steam, oil heating / oil, water cooling jacket	Plug / No neck valve
QLF-3500L	3500L	-0.098MPa	Electric, steam, oil heating / oil, water cooling jacket	Plug / No neck valve
QLF-4000L	4000L	-0.098MPa	Electric, steam, oil heating / oil, water cooling jacket	Plug / No neck valve
