Ocbs-T2220 Ocom 2D Omni-Directional Red LED Bar Code Reader Barcode Scanner
Basic Info.
Model NO.
OCBS-T220
Kind
Barcode Scanner
Scan Speed
300 scans/sec
Scanning Light Source
LED
Usage
Barcode Scanner
Network Scanning
Support Network
Interface Type
RS232, USB
Scanning Element
CMOS
Optical Resolution
300dpi
Application
Professional Image
Decoding Speed
65cm/S
Illumination
Red LED
OS Support
Microsoft Windows/Linux/Android/Ios/Macos
Current
115mA-510mA(Max)
Transport Package
1PCS in a Box
Specification
170*115*110mm
Trademark
OCOM/NEUTRAL/OEM
Origin
Shenzhen, China
HS Code
8443321300
Production Capacity
30000 Per Week
Packaging & Delivery
Package Size
18.00cm * 15.00cm * 15.00cm
Package Gross Weight
0.800kg
Product Description
Features: stylish design and suitable for a variety of application scenarios300,000 pixels Minimum resolution:4milsRed LED for illuminating scanning surfaceRead all mainstream 1D&2D bar codesQuickly read various screen bar codesSpecification
| General | |
| Model | OCBS-T220 |
| Color | Black |
| Interfaces | USB,RS232(customized) |
| Cable | 1.8M |
| Reading Indicators | LED/Buzzer |
| Input Voltage | 5 VDC/1A |
| current | 115mA(Working), 510mA(Max) |
| OS Support | Microsoft Windows/Linux/Android/IOS/MacOS |
| Drop resistance | Withstands repeated drops from 1.5m/4.0 ft onto a concrete surface |
| Performance | |
| Sensor | CMOS global shutter,640*480 Pixel |
| Pixel | 300,000 |
| Reading Precision | ≥4mil/0.1mm(PCS90%,CODE 39) |
| Depth of Field | 10mm~250mm(Different bar code range) |
| Decoding Speed | 65CM/S |
| Illumination | Red LED |
| Scanning mode | Auto,continuous |
| Reading Angle | Roll: ±360°,Pitch:±65°,Skew: ±60° (Test Conditions:CODE39,10mil/0.25mm,PCS90%) |
| Print contrast ratio(minimum) | ≥15% |
| Ambient Illumination | Dark Environment,Indoor Natural Light |
| Typical depth of Filed | Precision Barcode Depth of Filed 4mil CODE39 40mm-70mm 10mil CODE39 10mm-130mm 13mil UPC/EAN 10mm-160mm 20mil QR code 10mm-150mm etc..... (The minimum depth of field is determined by the barcode length and scanning angle. It depends on the print resolution, contrast and ambient light.) |
| Decoding ability | 1D:UPC-A,UPC-E,EAN-8,EAN-13,ISBN, ISSN, Code 128,GS1-128,ISBT, Code 39,Code 32, Code 93,Code 11,Codabar(NW-7),Interleaved 2 of 5,Matrix 2 of 5,Industrial 2 of 5(Straight 2 of 5),Standard 2 of 5(IATA 2 of 5),NEC 2of 5, MSI 2D: QR Code, Micro QR Code, Data Matrix,PDF417, Micro PDF 417, MaxiCode, Aztec,HanXin Code, Pharma Code(One-Track), Codablock A, Codablock F, Dot Code Other composite code:GS1 Databar(Omnidirectional, Limited, Expanded),GS1 Composite Code, TLC 39 Code. Chinese ID Card OCR , etc. Postal code:HongKong 2 of 5(China Post), Korea Post, Australian Post, British Post, USPS Intelligent Mail, Japanese Post, Planet Code, Postnet Code, UPU 4-State, KIX Code |
| Physical | |
| Weight | Gross:450g |
| Package | 170*115*110mm |
| Environment | |
| Working temperature& humidity | 0 to 45 degrees centigrade, 10%~80% No condensation |
| Storage temperature& humidity | -20 to 60 degrees centigrade , 10%~90% No condensation |
