45 Degree Straight Line Sintered Stone Tile Porcelain Quartz Stone Edging Grinding Chamfering Machine

Product Description

Product Parameters

The number of motors	5
Frame	Steel
Weight (gross weight)	2300KG
Linear guide/slider	T-win
Machine size	5550*2800*1500mm
Processing size	30-3200mm
Feeding Speeds	0.7-3m/min
Processing thickness	3-20mm
Pressure	0.6-0.8pa
Voltage	380v/50Hz/3P
Power	16.3KW

Detailed Photos

No.1	No.2	No.3	No.4	No.5
Resin wheel 120mesh	Saw blade Diameter:180M	Diamond wheel 60mesh	Resin wheel120mesh	Special-shaped wheel

Edging Effect
Our Advantages

Flat motor structure, stable chamfer does not break edge. The integrated positioning baffle is lifted by the bishaft cylinder, with strong stability and good accuracy. Independent cylinder control pressure block type pressure rod, firmly lock the sintered stone does not run off. Can be fixed more than 30mm plate, thick plate plate universal, firm and reliable. Frequency conversion speed regulating drive grinding head left and right movement, suitable for different speed requirements. Remote control structure, simple operation, convenient use, no special training, water, electricity, gas can be used. Oil immersed 30 linear guide rail, simple maintenance, stable operation. The unique smoothing function, suitable for different cutting methods of sintered stone, can achieve the smoothing, 45 degrees chamfering, crabapple edge, broom-finish, safety edge and other functional requirements. 5 Grinding wheel with low consumables.
Application Scenarios

Certifications
