Hot Selling 20 Ton Air Bottle Hydraulic Jack Garage Jack

Product Description

Capacity	Min.H	Lifting.H	Adjust.H	Max.H	N.W	Package	Measurement	Qty/Ctn	G.W	20' Container
(ton)	(mm)	(mm)	(mm)	(mm)	(kg)		(cm)	(pcs)	(kg)	(pcs)
2	158	90	60	308	2.23	Color Box	52x25.5x19	10	23	7800
3	195	125	60	380	3.2	Color Box	46x26.5x22.5	8	26	5400
4	195	125	60	380	3.2	Color Box	46x26.5x22.5	8	26	5400
5	197	125	60	382	4.1	Color Box	38x27.5x22.5	6	25	4200
6	197	125	60	382	4.1	Color Box	38x27.5x22.5	6	25	4200
8	205	125	60	390	4.9	Color Box	29.5x27.5x22.5	4	20	3340
10	205	125	60	390	5.6	Color Box	30.5x29.5x24	4	23	3000
12	215	125	60	400	6.5	Color Box	30.5x16.5x24	2	13.5	2500
15	225	140	60	425	7.8	Color Box	31.5x17x24.5	2	16	2250
16	225	140	60	425	7.8	Color Box	31.5x17x24.5	2	16	2250
20	244	145	60	449	10.2	Color Box	34.5x19.5x27	2	21	1500
25	244	145	/	389	10.2	Color Box	34.5x19.5x27	2	21	1500
30	285	180	/	465	14	Color Box	37.5x19.5x31	2	28.5	1240
32	285	180	/	465	14	Color Box	37.5x19.5x31	2	28.5	1240
50	300	180	/	480	29.5	Carton	26x24x33	1	30	540

Notes: 1.When the vehicle is jacked up,do not open the engine,because the engine vibrates and the weels of cars turned easy to cause the jack slide down. 2.Before operating the jack, find a fixed position. Operating Instruction 1.Before operating,estimate the weight of the load,Do not overload the jack beyond its rated load. 2.Select point of action according to the gravitational center place the jack on the hard ground if necessary,place a hard plank under the jack so as to avoid tottering or falling during operation. 3.Before operating the jacks,first,insert the notched end of the handle.into the release valve.Turn the operating handle clock wise until release value is closed.Do not over tighten the value. 4.Insert operating handle into the socket and the ram is steadily raised by the up and down movement of the handle and the load is raised.the ram will stop rising when the required height is reached. 5.Lower the ram by turning the release valve.Counterclockwise with the notched end slacken it slowly when a load is applied,or accidents can occur. 6.When more than one jack is used at the same time it is important to operate the different jacks at an equal speed with equal load.Otherwise,there is danger of falling the entire fixture. 7.Violent shocks must be avoided during the operation. 8.User must operate the jack correctly according to operating instruction:If the jacks has some quality problems,it can not be operated.

Our company offers variety of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
Q1: Are the pallet trucks covered by a warranty?
A: Yes. AII our products carry a full 1-year major parts warranty.
Q2: Can I get discounts?
A: Yes. For big orders, old customers, and frequent customers, we give reasonable discounts.
Q3: Can I place a mixed order? For example, I need 2 pcs electric stacker and 1 pc hand pallet truck, is it ok?
A: Of course. You can mix different models as you wish.
Q4: Can you add our own logo on the products or use our designs?
A: Of course, we provide OEM/ODM service. In addition, we promise your design would protect by law, we won't tell anyone else about this. It's your own copyright.
Q5: Can you send the products to my factory in another city to load the container?
A: Yes, please send us your detailed address, we will arrange to send your factory on time.
