Industry Conveyor Belt Sand Conveyor Belt

Product Description

Industry Conveyor Belt Sand Conveyor Belt
Top 5 conveyor belt manufacture in china
Huayue Conveyor Belt Competitive Advantage
1. Type: EP, Nylon, Steel cord, PVC, PVG, Sidewall, Chevron, Pattern, Cotton canvas, heat resistant, cold resistant, chemical resistant, Endless and so on.
2. Width (BW): 400-2200mm
3. Thickness: 4-30mm
4. We can add reinforced layer (1-2)
5. Abrasion resistant & High Tensile Strength
6. ISO9001: 2008, SGS, Bureau Veritas Certificate.
7. More Than 32 years professional experience. (Since 1982)
8. International Standard: DIN, BS, AS, RMA, AS, JISK, SABS etc
Application:
Belt is suitable in chemical industry, electric power, metallurgy, light industry, foodstuff machining and coal mine.
Variety:
According to the performance of covered-colloid products can be classified into designated crack-resistant, designated wear-resistant, general, and resistance to acid-base, and anti-burning.
Types:
General EP Belt, Fire-retardant type, Cold-resistant type, Wear-resistant type, Heat-resistant type, Acid and alkaline resistant type, Oil-resistant type, Antistatic electricity type, High-grade type and etc.
Standards:
GB/T7984-2001, DIN22102, BS490, AS1332, RMA, JISK6322, SABS1173 etc
Our best quality based on:
Manufacturer
Experience in Cooperate with Fortune 500 Companies
Professional Engineering Capability
Stable Quality
Reasonable Price
Small Orders Accepted
Continuous Improvements
High Product Performance
Prompt Delivery
Professional Service
About Huayue Company
Huayue is the Top 5 manufacturers and exporters ofConveyor Belt in ChinaSince 1982. Our range of conveyor belts are highly appreciated by our clients due to its Abrasion resistant feature and availability in various sizes and designs.
These are dimensionally accurate as per international standards.
Please feel free to let us know if you need any technical information.
Polyester conveyor belt, (EP)
Nylon conveyor belt, (NN)
Cotton conveyor belt, (CC)
Sidewall conveyor belt (SW)
Steel Cord conveyor belt ( ST )
Chevron conveyor belt, (C5 C10 and C15)
Oil Resistance conveyor belt, (OR and MOR)
Hot Resistance conveyor belt, (HR)
Fire Resistance conveyor belt, (FR/PVC/PVG)
Heat Resistance conveyor belt, (HR/ FR)
Cold Resistance conveyor belts, (CR)
Pattern conveyor belt ( 30+ Moulds)
Metal Mesh conveyor belt (Heat resistant temp until 800c)
Endless belts
Conveyor roller, idler
Conveyor Pulley, frame, bracket etc

Standards	Cover Rubber			Adhesion
	Tensile Strength	Elongation at break	Abrasion	Cover to Ply	Cover to Ply	Ply to Ply
DIN 22102	Mpa	%	mm3	N/mm (<=1.5mm)	N/mm (>1.5mm)	N/mm
DIN 22102-Z	15	350	250	3.5	4.5	5
DIN 22102-W	18	400	90	3.5	4.5	5
DIN 22102-Y	20	400	150	3.5	4.5	5
DIN 22102-X	25	450	120	3.5	4.5	5

Standards	Cover Rubber			Adhesion
	Tensile StrengTD	Elongation at break	Abrasion	Cover to Ply	Cover to Ply	Ply to Ply
AS 1332	Mpa	%	mm3	N/mm (≤1.9mm)	N/mm (>1.9mm)	N/mm
AS 1332-N17	17	400	200	4	4.8	6
AS 1332-M24	24	450	125	4	4.8	6

Standards	Cover Rubber			Adhesion
	Tensile StrengTD	Elongation at break	Abrasion	Cover to Ply	Cover to Ply	Ply to Ply
RMA	Mpa	%	mm3	N/mm (≤1.6mm)	N/mm (>1.6mm)	N/mm
RMA-I	17	400		3	4.4	4
RMA-II	14	400		3	4.4	4

Standards	Cover Rubber			Adhesion
	Tensile StrengTD	Elongation at break	Abrasion	Cover to Ply	Cover to Ply	Ply to Ply
SANS 1173	Mpa	%	mm3	N/mm		N/mm
A	18	400	70	5		7
C	20	400	150	5		7
M	25	450	120	5		7
N	17	400	150	5		7
