5 axis cnc controller HMU1000 board in turning milling machine

Product Description

Heavy duty cnc machining tool 5-axis cnc milling machine center price
Product Description
Product Parameters

Standard configurations: Equipped with 45° automatic indexing direct-drive milling head as standard X,Y,Z axis is equipped with linear scale, A, C axis is equippedwith circular time scale X,Y,Z axis hollow screw constant temperature water cooling 45T arm type tool magazine Direct-drive rotary table Siemens 840/ONE Equipped with double screw chip conveyor+double chain chip conveyor+top flushing chip as standard

Optional configurations: 40 pcs or 60pcs chain type tool magazine Automatic tool measuring system Automatic workpiece measuring system A.C-axis circular scale 2Mpa,3Mpa,5Mpa CTS Turning function,one time clamping can be completed turning, milling, boring and other forms of processing Units HMU1000 X-axis travel (coumn left-right movement) mm 1000 Y-axis tavel (forward and backward movement of rotay table) mm 1100 Z-axis travel (headstock up and down) mm 1000 A-axis rotary range ° -30°~+180° C-axis rotary range ° 360° Max.workpiece rotary diameter mm Ø 1100 Distance from spindle nose to table nose (spindle vertical) mm 150~1150 Distance from spindle axis to table rotation center(spindle vertical) mm -200~900 Distance from spindle axis to table surface (spindle horizontal) mm 50~1050 Distance from spindle nose to table rotation center (spindle horizontal) mm -100~1000 Table size mm 800*800 Min.indexing unit ° 0.001 Max.table load kg 2000 Rotary table speed rlmin 11.1 Max.spindle speed rpm 18000 Spindle taper HSK-A63 Spindle motor power KW 30 Spindle torque Nm 72/85 Rotational speed of the pendulum head rpm 60 Rated torque Nm 1200 Clamping system Hydraulic X/Y/Z rapid feed speed m/min 48 X/Y/Z max.cutting feed speed m/min 20 Max tool magazine capacity 45 Max tool diameter(full/empty) mm 75/130 Max tool length mm 350 Max,tool weight kg 8 Linear axis positioning accuracy X/Y/Z mm 0.008/0.008/0.008 Linear axis repeatable positioning accuracy X/Y/Z mm 0.005/0.005/0.005 Rotary axis positioning accuracy arc/sec 8 Repeatable positioning accuracy of rotary axis arc/sec 4 Control system model. SINUMERIK One Total control axes axes 5 Number of linkage control axes axes 5

Detailed Photos
TAIWAN PRECISION SPINDLE1. Spindle taper is HSK-A63;
2. Spindle speed 18000rpm
3. Spindle passed dynamic balance ISO rating test
TAIWAN TOOL MAGAZINE1. Standard with Taiwan 45 Arm tool magazine, tool change time only 3 seconds.
2. Brand: OKADA
LEAD SCREW AND COUPLINGTaiwan precision lead screw. Lead screw bearing use or NACHI bearing, 2. Coupling R+W directly connected .
TAIWAN PRECISION LINEAR RAILS
1. Taiwan high speed roller linear guide rail, positioning accuracy can reach μm class
2. Brand: HIWIN or PMI

Rotary worktable
Standard with rotary worktable.
TOOL UNCLAMP CYLINDERTaiwan spindle Tool unclamp cylinder

CONTROL SYSTEMStandard: Siemens 840D/ Siemens ONE control
Optional : GSK etc.
AIR STORAGE TANKAir storage tank to ensure the stability of spindle tool change

AIR CONDITIONERStandard with Industrial electrical cabinet air conditioner. Cooling the electric box better .
LUBRICATION SYSTEM Automatic centralized lubrication device .
ELECTRICAL COMPONENTS1. with safety electrical components
2. quick plug as standard
PNEUMATIC COMPONENTS
Standard with Pneumatic Components

AIR GUN AND WATER GUNHigh-pressure air guns and high-pressure water guns

TESTING Each machine passed Renishaw laser interferometer testing and ballbar testing

MACHINE CONSTRUCT High strength high quality cast iron, 2. long span bed base and vertical column structure

SPINDLE RING COOLING
Standard with Spindle ring cooling function.
