Basic Info.
Interface
USB, Serial Port
Application
Parking, Hospital, Library, Company, Bank, Store, Warehouse
Working Frequency
860-960MHz
Protocl
ISO18000-6c, EPC Gen2 Class One
Transport Package
Factory Box
Specification
179*80*17.2mm
Production Capacity
5000/Moth
Product Description
Product Parameters
Dimension | 179mm(H)x80mm(W)x17.2mm(D)±2 mm |
Weight | Net Weight :654 g |
Display | Gorilla Glass 3 9 H 5 . 5 in. TFT- LCD (720 x1440 )touch screen with backlight |
Battery | Rechargeable li- ion polymer, 3.8V, 9000 mAh |
Operating System | Android12.0 |
Storage | 2GB RAM/ 16GB ROM or 4GB RAM/ 64 GB ROM Micro SD( max 256 GB expansion) |
Sealing | IP65 , IEC compliance |
SDK | Java |
2D barcode-Optional | 2D CMOS Imager :Zebra SE 4710 SE 2100 / Others Symbologies: PDF417, MicroPDF417, Composite, RSS, TLC3 9 , D a t a m a t r i x , Q R code, Micro QR code, Aztec, Maxi Code, P o s t a l C o d e s , U S Post Net, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal. etc. |
RFID READER(OPTIONAL) | Low Frequency:125 KHz/ 134 . 2 KHz (FDX- B/HDX) NFC:13 . 56 MHz ISO 14443 A& 15693 , NFC- IP1, NFC- IP2 UHF:865 ~ 868 MHz or 920 ~ 925 MHz ,EPC C 1 GEN 2 ISO 18000 -6C |
Antenna Gain | Circular antenna( 3dBi) |
Battery | 10000mhA |
Company Profile Our Group company is a professional provider of RFID products and IoT solutions. with 8 subsidiaries located in Guangdong,
Shenzhen, and Quanzhou, China. We have been focusing on the production, design, and R&D of RFID hardware for over 15 years.
serving more than 6000 customers and employing over 300 employees.The factory has passed ISO9001,SGS and the products
have passed CE and Rohs. We have 5 smart card production lines,10 RFID sticker production lines, 4 RFID industrial tag production
lines, and 4 RFID equipment production lines. cooperated with ZEBRA, Alien Technology,N-X-P,FUDAN Microelectronics.
Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the
trend of economic globalization has developed with anirresistible force.
FAQ Q: Are you trading company or manufacturer ?
A: We are factory with trading department.
Q: How long is your delivery time ?
A: Generally it is 3-7 days if the goods are in stock. Or it is 8-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance.
B: Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Q: What's the after-sales services ?
A: Each of our products are inspected by QC department, 100% ensure the perfect quality before shipment. We will replace it if you receive defective products. We are responsible for each products we sell.
WHY CHOOSE US ? 1.We are factory! we not only offer factory prices, but also support OEM and ODM !
2.24-Hour Hour Hotline !
3.If the quality issue is caused by our factory's mistake, we support a 100% refund !
4.Provide top-notch technical support in the industry !
5.Lifelong service !
