Super Bright 3030SMD High Lumen 130lm-140lm/W Light Sensor Photocell Outdoor Light 300W LED Street Light
Basic Info.
Model NO.
LD051B-300W
Lamp Body Material
Aluminum
Power
300W
Application
Square, Highway, Garden, Parking Lot
IP Rating
IP66
Certification
CE, RoHS
Input Voltage
85-265V
With Light Source
With Light Source
LED Chips Brand
Sanan
Luminous Flux
130-140lm/W
SPD
6kv
Warranty
3 Years
Color Box
267*102*790
Carton
800*320*282
Qty/CTN
3PCS
Transport Package
Color Box and Carton
Specification
781*263*100
Trademark
OEM
Origin
Guangdong Jiangmen
HS Code
9405409000
Packaging & Delivery
Package Size
80.00cm * 32.00cm * 28.20cm
Package Gross Weight
10.650kg
Product Description
Super bright 3030smd high lumen 130lm-140lm/w light sensor photocell outdoor light 300W led street light Product Parameters Product Parameter| MODEL | LD051B-50W | LD051B-100W | LD051B-150W | LD051B-200W | LD051B-300W |
| POWER | 50W | 100W | 150W | 200W | 300W |
| LED QTY | 72PCS-3030SMD | 144PCS-3030SMD | 216PCS-3030SMD | 288PCS-3030SMD | 360PCS-3030SMD |
| Luminous Flux | 130-140LM/W | 130-140LM/W | 130-140LM/W | 130-140LM/W | 130-140LM/W |
| Input Voltage | Isolated 100-265V | Isolated 100-265V | Isolated 100-265V | Isolated 100-265V | Isolated 100-265V |
| Withstand Voltage | 1500V | 1500V | 1500V | 1500V | 1500V |
| Anti-surge | 6KV | 6KV | 6KV | 6KV | 6KV |
| Power Factor | >0.9 | >0.9 | >0.9 | >0.9 | >0.9 |
| Color Rendering Index | >80 | >80 | >80 | >80 | >80 |
| Color Temperature | 3000-6500K | 3000-6500K | 3000-6500K | 3000-6500K | 3000-6500K |
| IP Rating | IP66 | IP66 | IP66 | IP66 | IP66 |
| Beam Angle | 80-145° | 80-145° | 80-145° | 80-145° | 80-145° |
| Housing Color | Grey/Black | Grey/Black | Grey/Black | Grey/Black | Grey/Black |
| Working Temp | -30ºC~50ºC | -30ºC~50ºC | -30ºC~50ºC | -30ºC~50ºC | -30ºC~50ºC |
| Humidity | 10%~95%RH | 10%~95%RH | 10%~95%RH | 10%~95%RH | 10%~95%RH |
| Body Material | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy | Aluminum alloy |
| Life Time | >30000Hrs | >30000Hrs | >30000Hrs | >30000Hrs | >30000Hrs |
| Warranty | 3 Years | 3 Years | 3 Years | 3 Years | 3 Years |
| Dimension L*W*D(mm) | 465*153*100(ø60) | 560*183*100(ø60) | 678*213*100(ø60) | 730*233*100(ø60) | 781*263*100(ø60) |
| Net Weight(kg) | 1.04 | 1.42 | 1.94 | 2.74 | 2.95 |
300W FRONT
300W BACK Product Description
