China Rubber Crawler Small Mini Digger Excavator
| US$9,000.00-15,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
20 Excavator
Type
Crawler Excavator
Usage
Mining Excavator
Bucket
Backhoe
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.05
Size
Small-Scale
Certification
CE, ISO9001: 2000
Condition
New
Customized
OEM and ODM
Color
Customizable Colors
Core Component
Engine, Motor, Pump
Engine
Yangma 3tnv70
Hydraulic Pump Brand
Doosan
Hydraulic Valve Brand
Kyb
Hydraulic Cylinder Brand
Liyuan
Machinery Test Report
Provided
Video Outgoing-Inspection
Provided
Transport Package
Custom Wooden Case Packing
Trademark
LONGET
Origin
Shandong, China
HS Code
8429521200
Production Capacity
500
Product Description
Product Description
1. The mini excavator is equipped with top-brand engines, such as Yanmar or Kubota, satisfying the EURO5 and EPA Tier4 emission standards.
2. Based on the rich manufacturing experience, the engines and hydraulic systems are matched perfectly. So the mini excavators enjoy the best efficiency and performance.
3. The whole body adopts the reinforced material, making it stronger and more durable.
4. Many tools could be attached to complete various jobs, such as Hammer, Auger, Rake, Thumb, Grapple, etc.
Color Customization
Product Parameters
| ITEM | PARAMETER(METRIC) | PARAMETER(BRITISH) |
| Operating Weight | 2000 Kg | 4409 lb |
| Digging Bucket Capacity | 0.045 cbm/100kg | 0.045 cbm/220Ib |
| Bucket Width | 680 mm | 26.7 in |
| WheelBase | 880 mm | 34.6 in |
| Total Length of Track | 1240 mm | 48.8 in |
| Chassis Width | 990 mm | 38.9 in |
| Track Width | 180 mm | 7.1 in |
| Max. Digging Depth | 2310 mm | 90.9 in |
| Max. Vertical Digging Depth | 2036 mm | 80.1 in |
| Max. Digging Height | 3720 mm | 146.4 in |
| Max. Dumping Height | 2260 mm | 88.9 in |
| Max. Digging Radius On Ground | 3600 mm | 141.7 in |
| Min. Rotation Radius | 1850 mm | 72.8 in |
| Travel Speed | 2.7 Km/h | 1.68 mph |
| Max Upgrade Height of Bulldozer Blade | 165 mm | 6.5 in |
| Max Digging Depth of Bulldozer Blade | 170 mm | 6.69 in |
| ITEM | PARAMETER(METRIC) | PARAMETER(BRITISH) |
| Engine | Yangma 3TNV70 | |
| Fuel | Dieselor | |
| Gross Power Rating | 14 HP | 10 kw |
| Number of Cylinders | 3 | |
| Displacement | 0.854 L | 52.1 in³ |
| Rated Speed | 2200 rpm | |
| Fuel Tank Capacity | 30 L | 7.92 gal |
| Engine Oil, w/filter | 3.7 L | 4.2 qt |
| Hydraulic Reservoir Capacity | 35 L | 9.2 gal |
| Electrical System | 12V | |
Company Profile
We have rich experience in the manufacture of Loader-Digger, Mini Excavator and Skid Steer Loader.
Our Advantages
1) Pre-sale service:We could assist you finding the suitable equipment according to your requirement.2) On-sale service:We strictly follow the commercial rules, contract signing. Follow the production process, control the goods quality, track the goods delivery, guarantee you receive the qualified goods safely.3) After-sale service:Provide some consumables with the equipment;Provide operation manual for instructing the basic installation and operation;Provide video guidance for trouble shooting.
